ABB SDCS-PIN-4-COAT (3ADT314100R1001) DCS800 Power Interface Board

SKU SDCS-PIN-4-COAT 3ADT314100R1001

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB
  • Product No.: SDCS-PIN-4-COAT 3ADT314100R1001
  • Origin China
  • Product Type: Power Interface Board
  • Barcode: 85049099
  • Payment: T/T, Western Union
  • Weight: 0.67 kg
  • Dimensions: 245 mm x 175 mm x 60 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

DCS800 Power Interface Boards
Quantità
Call sales Contact

Product Description

Description

The ABB SDCS-PIN-4-COAT is a ruggedized power gate distribution card engineered for three-phase industrial thyristor power converters operating within variable-speed DC drive topologies. Performing as the main power interface board for the assembly, this specialized circuit module accurately scales line synchronization telemetry, bridges localized analog feedback loops, and processes active firing commands for high-current semiconductor networks.

To withstand demanding industrial processing zones, this unit is equipped with a high-grade conformal coating that insulates its internal electronics against metallic particulates, moisture, chemical micro-vapors, and typical environmental debris. The hardware routes drive gating pathways, safely balances high-potential phase potentials, and establishes a secure electrical boundary between the low-voltage processing cards and high-voltage line supplies up to 525 VAC.

Features

  • Conformal Coated Surface: Upgraded chemical coating provides critical dielectric tracking resistance and protection against airborne pollutants in heavy-duty plants.
  • Galvanic Gate Isolation: Built-in isolation circuits block upstream propagation of extreme back-EMF transients generated during high-load switching events.
  • Precision Line Synchronization: Integrates highly stable voltage attenuation networks to ensure clean, jitter-free phase detection under non-linear grid conditions.

Applications

  • Thyristor firing generation and line measurement tracking inside ABB DCS800 power converters.
  • Heavy industrial DC motor drives used in paper processing facilities, deep mining hoists, polymer extrusion lines, and metal rolling mills.

Technical Specifications

Parameter Specification
Manufacturer ABB
Model Designation SDCS-PIN-4-COAT
Product ID / Order Number 3ADT314100R1001
Device Classification Power Interface Board
Board Treatment Industrial Conformal Coating
Customs Tariff Number 85049099
UNSPSC Classification 39120000
Part Type Status Original / New
Country of Origin China (CN)
Product Net Weight 0.670 kg
Shipping Weight (Calculated) 0.820 kg
Package Dimensions (Calculated) 245 mm x 175 mm x 60 mm

Alternative Models & Compatibility

The SDCS-PIN-4-COAT board functions as the direct factory replacement upgrade for older, uncoated legacy SDCS-PIN-4 variants. Its identical mounting footprint and shared socket spacing permit an efficient drop-in swap inside standard electronics trays. Adding the robust conformal film improves electrical safety margins in high-moisture or metallic dust facilities without modifying standard drive calibration values or gating timing curves.

Installation Guidelines

CRITICAL WARNING: HIGH-VOLTAGE DISCHARGE HAZARD

Isolate, decouple, and lock out all incoming three-phase main lines, field supply feeds, and auxiliary power routes before removing panel enclosures. Converter systems retain dangerous capacitive energy charges after supply disconnection. Wait at least 15 minutes for complete internal voltage depletion, and verify zero potential across all power terminal pins with a rated multi-meter before handling internal boards.

1
Fasten a verified electrostatic discharge (ESD) wrist strap to an unpainted metal grounding surface to ground static charges before touching raw circuit areas.
2
Carefully map, document, and remove all multi-pin ribbon cables, bridge telemetry wire links, and primary thyristor gate firing connectors from the terminal headers.
3
Loosen the standoff screws on the frame, remove the existing card, align the new coated board into position, tighten all fasteners to ensure chassis grounding path continuity, and securely reseat all wire plugs.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
