ABB

ABB TC625 3BSE002224R1 Advant Master AF100 Coaxial Modem

SKU 3BSE002224R1

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: ABB
Product No.: 3BSE002224R1
Origin Sweden
Product Type: Coaxial Modem
Barcode: 85176200
Payment: T/T, Western Union
Weight: 0.29 kg
Dimensions: 4.4 cm x 15 cm x 17.6 cm
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantità

Call sales Contact

Product Description

The ABB TC625 is a hardware infrastructure interface module designed for the Advant Master Process Control System to manage deterministic data transportation across coaxial physical segments. This specialized communication link executes media translation protocols, working under product ID 3BSE002224R1 and Type Designation TC625, to bridge processing networks over Advant Fieldbus 100 (AF100) configurations. Engineered without internal cooling fans, this device drives electrical signals along high-integrity coaxial networks to sustain zero-packet-loss routing within centralized plant grids. The unit is optimized for multi-node automation topologies, protecting time-critical application loops from physical signal degradation while supporting full compatibility with core communication backplanes and dedicated transceiver sets.

Key Features

Direct translation architecture optimizing raw signal conversion on active AF100 industrial fieldbuses.
Exempted from 2011/65/EU RoHS scope per specialized heavy industry system provisions.
Exchange component configuration matching exact factory cross-references under code EXC3BSE002224R1.
Rugged modular casing built to slot securely into dedicated industrial sub-rack tracks.

Target Deployment

Advant Controller 450 Version 2.3 logic sub-racks running complex process control topologies.
Advant Controller 410 Version 1.5 installations requiring expanded remote node networking.
System 800xA control infrastructure utilizing active Advant Fieldbus 100 interface blocks.

System Compatibility Kit

This un-bundled modem component integrates natively into standard corporate system kits and designated transceiver layouts:

Kit Identifier	Kit Component Nomenclature	Qty	Unit
3BSE014070R1	AF 100 Communication set	1	piece
3BSE018448R1	CI522AK01 AF 100 Comm. Interface	1	piece
3BSE018449R1	CI522AK02 AF 100 Interface for Bus	1	piece
3BSE018450R1	CI522AK03 AF 100 Interface for Bus	1	piece

Technical Specifications

Parameter	Certified Engineering Data
Manufacturer	ABB
Product Type	Communication_Module
Sub-Category	TC625 Advant Fieldbus 100 Coaxial Modem
Alternative Cross-Reference ID	EXC3BSE002224R1
Customs Tariff Number	85176200
HS Code Description	Machines for the reception, conversion and transmission or regeneration of voice, images or other data
Product Net Weight	0.29 kg
Country of Origin	Sweden
Shipping Weight (Calculated)	0.48 kg
Package Dimensions (Calculated)	245 mm x 160 mm x 60 mm

Field Installation Protocol

Follow precise sequence parameters to mount or swap out infrastructure interfaces safely on system sub-racks.

Critical Warning: Network Segregation & Zero-Energy State

Isolate auxiliary and main power feeds from the target Advant Controller rack prior to module insertion or removal. Handling coax field modems under active current risks dangerous transient signal reflection, hardware register lockup, or unexpected breakdown of adjacent communication loops.

Sub-Rack Power Isolation & ESD Grounding Completely isolate the sub-rack power supply module (such as the SA16x setup). Wear a grounded ESD wrist strap connected to the cabinet frame before unpacking the replacement unit to protect the sensitive hardware registers from static discharge.

Hardware Address & Jumpers Verification Before inserting the card, inspect the onboard hardwired jumper links (e.g., S1/S2 positions) against the original plant loop layout documentation. Ensure the hardware identification settings precisely match your existing Advant Controller node scheme.

Module Alignment, Seating & Mechanical Earthing Align the TC625 PCB edges accurately within the upper and lower plastic channel tracks of the sub-rack. Smoothly push the module back until its DIN connector fully mates with the system backplane. Securely torque the top and bottom captive screws to establish proper mechanical chassis earthing.

Coaxial Bus Termination & BNC Locking Connect the heavy industrial RG-6 or RG-11 coaxial physical drop segments using the dedicated BNC T-connectors. Twist the locking sleeves until fully clicked into place to shield against industrial EMI. If this modem serves as the physical endpoint of the AF100 bus topology, verify that a certified 75Ω coaxial termination resistor is securely installed on the vacant side of the BNC tee.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

Which fieldbus architecture does this device interface with?

This module interfaces directly with Advant Fieldbus 100 networks to drive deterministic data via coaxial distribution mediums.

Is this component compliant with standard RoHS directive timelines?

No. The device is officially exempted from the scope of directive 2011/65/EU under standard provisions for specialized process control system hardware.

Can I replace an active unit without shutting down power to the rack?

No. Power feeds to the specific Advant Controller sub-rack section must be fully isolated before removal or installation to prevent signal reflection.
