ABB TU837V1 3BSE013238R1 S800 I/O Module Termination Unit

SKU TU837V1 3BSE013238R1

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB
  • Product No.: TU837V1 3BSE013238R1
  • Origin Bulgaria
  • Product Type: Module Termination Unit
  • Barcode: 85371098
  • Payment: T/T, Western Union
  • Weight: 0.37 kg
  • Dimensions: 120.5 mm x 110 mm x 64 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Module Termination Units S800 I/O

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

ABB TU837V1 3BSE013238R1 S800 I/O Module Termination Unit

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The ABB TU837V1 3BSE013238R1 is an Extended Module Termination Unit designed for the ABB S800 I/O system. The TU837V1 functions as a base for I/O modules, providing a 250V rating and accommodating fused isolated signals. The termination unit incorporates 8x1 fused isolated signals, 8x1 L terminals, and 2x6 N terminals for comprehensive field wiring connections. This component supports multiple ABB control platforms, including 800xA, Advant OCS, and the Compact Product Suite.

Features

  • Extended Module Termination Unit configuration.
  • Rated for up to 250V applications.
  • Provides termination for 8x1 fused isolated signals.
  • Includes 8x1 L terminals and 2x6 N terminals.

Applications

  • I/O module base termination in ABB S800 I/O systems
  • ABB 800xA System I/O installations
  • ABB Advant OCS with Master SW / MOD 300 SW field wiring
  • ABB Compact Product Suite I/O infrastructure

Technical Specifications

Parameter Value
Manufacturer ABB
Model Designation TU837V1
Product ID 3BSE013238R1
Product Type Module Termination Unit
Voltage Rating 250V
Terminal Configuration 8x1 fused isol. signals, 8x1 L terminals, 2x6 N terminals
HS Code 853710
Customs Tariff Number 85371098
Product Net Width 110 mm
Product Net Height 120.5 mm
Product Net Depth / Length 64 mm
Product Net Weight 0.37 kg

Installation Guidelines

  • Ensure power is disconnected from the I/O subsystem prior to installing or wiring the termination unit.
  • Verify the I/O module to be installed is compatible with the TU837V1 250V extended fused configuration.
  • Route field wiring correctly to the designated 8x1 fused, 8x1 L, and 2x6 N terminals.
  • Ensure secure mounting within the designated control cabinet structure.

Compliance and Certifications

  • RoHS Information: Following EU Directive 2011/65/EU
  • WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the ABB TU837V1 3BSE013238R1 used for?
The ABB TU837V1 3BSE013238R1 is an Extended Module Termination Unit used to mount and provide field wiring connections for S800 I/O modules.
What terminal configurations does the extended MTU provide?
The termination unit provides 8x1 fused isolated signals, 8x1 L terminals, and 2x6 N terminals.
Which systems is the termination unit compatible with?
The MTU is compatible with the S800 I/O system, used across ABB 800xA, Advant OCS, and Compact Product Suite platforms.
What is the voltage rating of the MTU?
The extended module termination unit is rated for 250V.
