Allen-Bradley

Allen-Bradley 1492-AIFM6S-3 Analog Interface Module

SKU 1492-AIFM6S-3

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Allen-Bradley
  • Product No.: 1492-AIFM6S-3
  • Origin United States
  • Product Type: Analog Interface Module
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.25 kg
  • Dimensions: 83 mm x 87 mm x 71 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Analog Interface Modules

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Allen-Bradley 1492-AIFM6S-3 Analog Interface Module

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The Allen-Bradley 1492-AIFM6S-3 is a feed-through 6-channel isolated Analog Interface Module (AIFM) designed for programmable controller wiring systems. It provides direct connection points between field wiring and I/O modules, utilizing 3 to 4 terminals per channel for streamlined field-side signal termination.

Features

  • Feed-through 6-channel isolated design.
  • 3 to 4 terminals per channel for field-side connections.
  • Six field-side shield terminals jumpered together internally and connected directly to the D-shell housing.
  • Standardized D-shell connector interface for pre-wired cable connection to programmable controller I/O modules.

Applications

  • Wiring interface for programmable logic controller (PLC) isolated analog input/output systems.
  • Industrial process control systems requiring field-side analog signal termination and shield grounding.

Technical Specifications

Parameter Specification
Manufacturer Allen-Bradley / Rockwell Automation
Model 1492-AIFM6S-3
Module Type Analog Interface Module (AIFM)
Number of Channels 6 Channels (Isolated)
Terminals per Channel 3...4 Terminals
Wiring Topology Feed-Through
Shield Connection 6 field-side terminals jumpered to D-shell housing

Connections/Interfaces

Connector Pin Function
D-Shell Housing Internal connection to 6 jumpered field-side shield terminals

Installation Guidelines

  • Compatibility Check: Ensure the operating voltage and current ratings of the system do not exceed the ratings of the AIFM for proper operation.
  • Field Wiring: Refer to the label section and specific field-side wiring diagrams before terminating field conductors.
  • Shield Grounding: Utilize the jumpered shield terminals to ground cable shielding through the D-shell housing.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
How many channels does the module support?
The module supports 6 isolated channels.
How are the shield terminals connected within the module?
Six field-side shield terminals are jumpered together on the module and internally connected to the D-shell housing.
How many terminals are provided per channel?
The module provides 3 to 4 terminals per channel.
