The Allen-Bradley 80190-100-01-R is an optical interface printed circuit board engineered by Rockwell Automation to provide robust power regulation and isolated fiber optic communication interfaces. The 80190-100-01-R serves as a dependable power conversion module that delivers a stable 24V DC output up to 10A from an adjustable input range of 100-240V AC. This hardware integrates multi-channel fiber optic transmitter and receiver paths alongside power regulation components, ensuring stable power delivery and transient-immune communication interfaces for demanding industrial automation applications.
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Model Number | 80190-100-01-R |
| Alternate Board Marking | 80190-099-01/6 |
| Input Voltage Range | 100-240V AC |
| Output Voltage Range | 24V DC |
| Maximum Output Current | 10A |
| Power Output | 240W (max) |
| Enclosure Type | IP20 |
| Operating Temperature Range | -20 degC to 60 degC (-4 degF to 140 degF) |
| Storage Temperature Range | -40 degC to 85 degC (-40 degF to 185 degF) |
| Country of Origin | Canada (Designed in USA) |
