Designed for seamless integration into control cabinets and 19-inch racks, the Beckhoff C6240-0070 provides high-performance computing capability for complex automation architectures. This industrial PC is built around a robust stainless steel housing, engineered specifically to withstand the thermal and physical demands of harsh industrial environments. Equipped with an ATX motherboard, the system accommodates 6th and 7th generation Intel processors, offering flexible scalability from dual-core Celeron configurations up to high-performance quad-core Intel Core i7 processors.
The system configuration of this control cabinet industrial PC features highly expandable slot options, allowing for the integration of up to seven plug-in cards. System reliability is enhanced by an on-board SATA RAID 1 controller and versatile storage options, making it ideal for high-availability applications such as SCADA systems, centralized machine control, and complex visualization tasks.
| Manufacturer | Beckhoff |
| Model/Part Number | C6240-0070 |
| Device Type | Control Cabinet Industrial PC |
| Housing Material | Stainless steel |
| Processor | Intel Celeron G3900 2.8 GHz, 2 cores (Option: Up to Intel Core i7 7700 3.6 GHz, 4 cores) |
| Motherboard | ATX motherboard for Intel 6th/7th generation processors |
| Memory | 4 GB DDR4 RAM (Option: Scalable up to 64 GB DDR4 RAM) |
| Expansion Slots | 2 x PCIe-x1, 2 x PCIe-x4, 1 x PCIe-x16, 2 x PCI (for cards up to 190 mm length) |
| Storage | 1 TB 3.5-inch hard disk (Option: Up to 4 TB HDD, SSD, or CFast) |
| Graphics | Integrated in the processor |
| Ethernet Ports | 2 x 100/1000BASE-T on-board |
| Power Supply | 100 to 240 V AC (Option: 24 V DC, integrated UPS) |
| Protection Rating | IP20 |
| Operating Temperature | 0 to 55 degC |
| Dimensions (W x H x D) | 430 x 170 x 274 mm |
| Weight | 12.3 kg (basic configuration) |
| Interface Connection | Function / Description |
|---|---|
| USB Ports | 4 x USB 3.0 ports (Option: Up to 10 x USB 2.0) |
| Video Outputs | 2 x DVI, 1 x DisplayPort |
| Serial Interface | 1 x RS232 port (Option: Up to 3 x RS232) |
| Ethernet Interface | 2 x RJ45 (100/1000BASE-T) |
| Keyboard/Mouse | PS/2 connection ports |
Global Express Shipping
Returns & Warranty
Manufacturer: BECKHOFF
Product No.: C6240-0070
Country of origin:Germany
Product Type: Control Cabinet Industrial PCs
Payment: T/T, Western Union
Weight: 12300g
Dimensions: 430 x 170 x 274 mm
Shipping port: Xiamen
Warranty: 12 months
