Description
Engineered for direct mounting arm integration, the Beckhoff CP3913-0010 operates as a robust, industrial-grade human-machine interface featuring advanced CP-Link 4 connectivity. This Control Panel features a high-performance 12.1-inch widescreen display protected by a durable glass front and housed in a rugged aluminum enclosure. It utilizes projected capacitive touch technology to support multi-finger interaction, even in harsh manufacturing environments. Operating over the CP-Link 4 protocol, this terminal consolidates DVI, USB 2.0, and power signals into a single standard Cat.6A cable, allowing complete operational control up to 100 meters away from the industrial PC without signal degradation.
Features
-
High-Resolution Widescreen Display: 12.1-inch TFT display panel supporting up to 1280 x 800 pixels with high contrast and wide viewing angles.
-
CP-Link 4 Interface: Transmits DVI, USB 2.0 (100 Mbit/s), and power over distances up to 100 meters via standard Ethernet Cat.6A cabling.
-
Rugged Industrial Enclosure: Premium aluminum housing with a seamless IP65-rated glass front panel to resist moisture, dust, and particulate ingress.
-
Capacitive Multi-Touch: Supports complex gesture controls, multi-finger input, and operation with thin industrial work gloves.
-
Flexible Mounting Options: Integrated connection block with 4 x M6 threaded holes spaced at 100 x 100 mm, designed for versatile rotatable and tiltable mounting arm system integration.
Applications
- Automotive assembly line visualization and machine diagnostics.
- Material handling and robotic workstation control cells.
- Process control monitoring in pharmaceutical and food packaging lines.
- Direct machine-level operation requiring overhead or swing-arm mounted terminals.
Technical Specifications
| Parameter |
Specification Value |
| Manufacturer |
Beckhoff |
| Model / Article Number |
CP3913-0010 |
| Display Size |
12.1-inch (Widescreen) |
| Resolution |
1280 x 800 pixels |
| Touch Screen Technology |
Projected Capacitive Touch (PCT) Multi-finger |
| Interface Type |
CP-Link 4 (One Cable or Two Cable Technology) |
| Maximum Distance |
Up to 100 meters via Cat.6A cable |
| Connectors |
2 x M12 round connectors (IP65 rated) |
| Housing Material |
Aluminum housing with clean glass front |
| Protection Class |
IP65 (Full protection against dust and low-pressure water jets) |
| Operating Temperature |
0 to 50 degC |
| Mounting Thread Pattern |
4 x M6 threaded holes, 100 x 100 mm matrix spacing |
| Shipping Weight (Calculated) |
5.0 kg |
| Package Dimensions (Calculated) |
420 mm x 320 mm x 150 mm |
Connections and Interfaces
| Connector Port |
Pin / Keying Type |
Functional Assignment |
| Connector 1 (CP-Link 4) |
M12, X-coded, 8-pin female |
CP-Link 4 High-speed Signal (Video, USB 2.0, and Power-over-Ethernet equivalent configuration) |
| Connector 2 (Auxiliary Power) |
M12, T-coded, 4-pin male |
Optional external 24 V DC power supply input (Used for Two-Cable Technology setups) |
Empirical Engineering Insights
Alternative Models & Compatibility
The CP3913-0010 operates within the Beckhoff CP39xx high-performance arm-mounted control series. It represents a direct technology transition from older DVI/USB-extended physical connections to the single-cable CP-Link 4 standard. Note that this module requires a corresponding CP-Link 4 transmitter unit installed on the PC side—such as the CU8802 or CU8803 PCIe transmitter cards—to handle the combined data transmission over 100-meter segments.
Application Pitfalls & Engineering Notes
When utilizing One Cable Technology (OCT) where power is delivered alongside signals over a single Cat.6A cable, check the total power loss characteristics of your cabling. Low-quality or non-shielded cables can induce packet drops or sudden display resets if routed parallel to high-voltage variable frequency drive (VFD) output cables. Ensure physical separation of at least 20 cm from main power lines in control trays.
Commissioning & Wiring Tips
Always utilize genuine Beckhoff pre-assembled M12 Cat.6A industrial patch cords to guarantee signal integrity up to 100 meters. Before hot-plugging the CP-Link 4 connector, verify that the transmitter card is powered down. Ensure the mounting arm's metallic structure is bonded to the main machinery ground strap to dissipate static build-up on the glass capacitive touch interface.
Installation Guidelines
CRITICAL WARNING: De-energize all power distribution systems feeding the transmitter unit and auxiliary power supplies prior to starting the physical installation. High voltage arcs can damage sensitive internal capacitive touch controllers. Confirm that the mounting arm assembly is mechanically rated to support a static load of at least 15 kg before installing the Control Panel.
1
Inspect the connection block's gasket and verify that the 4 x M6 mounting thread holes are free of debris. Align the bracket adapter with the mounting pattern on the rear panel.
2
Secure the unit to the mounting arm using M6 screws with a thread engagement depth between 8 mm and 12 mm. Hand-tighten in an alternating sequence to a torque of 4.5 Nm.
3
Route the Cat.6A cable through the mounting arm tube, avoiding sharp bends (ensure minimum static bend radius of 8x cable diameter). Connect the X-coded M12 CP-Link 4 cable to Connector 1, securing the threaded lock collar firmly.
4
For Two-Cable systems, connect the 24 V DC auxiliary power supply to the B-coded M12 Connector 2. Verify ground-fault resistance before energizing the control system.
