Description

Designed for demanding industrial control and visualization applications, the Beckhoff CP6521-0000-0090 serves as a robust built-in Panel PC featuring an integrated 12-inch TFT display. This unit combines high-performance processing capabilities with a rugged control panel, optimized for direct integration into control cabinets or operator consoles. Equipped with a 7-slot ATX housing, it allows for versatile expansion with standard plug-in cards to meet specific automation requirements. The front panel provides IP65-rated protection against dust and moisture, while the pull-out clamping levers facilitate rapid, secure installation without loose parts.

Features

• Integrated 12-inch TFT display with a resolution of 800 x 600 pixels.
• 7-slot ATX housing accommodating plug-in cards up to 190 mm in length.
• Fast, tool-free installation using integrated pull-out clamping levers.
• Dual-zone protection rating: IP65-rated front panel and IP20-rated rear enclosure.
• Support for high-capacity DDR4 RAM and versatile processor configurations.
• Multiple onboard interface options including USB 3.0, DVI, DisplayPort, and dual Gigabit Ethernet.

Applications

• Machine tool control and factory floor visualization.
• Automotive assembly line monitoring and execution systems.
• Power generation and process industry control panels.
• Custom operator station integration in harsh manufacturing environments.

Technical Specifications

Installation Guidelines

Ensure the mounting cutout matches the physical dimensions of the 12-inch display housing. Insert the Panel PC into the cutout and extend the pull-out clamping levers to lock the unit securely into place. Maintain adequate ventilation clearance at the rear of the ATX housing to ensure operating temperatures do not exceed 55 degC. Ground the housing in accordance with local electrical safety regulations. Route signal and communication cables separately from high-voltage power lines to minimize electromagnetic interference.
