Designed for space-saving control cabinet installation, the Beckhoff CP6732-0000-0060 serves as a compact, high-performance built-in Panel PC combining visual display and control computing. This industrial PC features a 15-inch TFT display with a resolution of 1024 x 768 pixels, providing sharp visual readouts for industrial machine environments. Constructed with an aluminum front panel and a sheet-steel rear cover, it delivers robust structural integrity suitable for demanding plant floors.
The processing architecture is built around the Intel Atom x5 series on a 3.5-inch motherboard, optimized for energy-efficient execution of PLC and motion control tasks. Designed without rotational components when paired with CFast flash storage, the fanless system operates reliably under continuous industrial conditions. Dual integrated Gigabit Ethernet ports and multiple USB interfaces allow for seamless connectivity to EtherCAT networks, control networks, and local peripheral devices.
| Manufacturer | Beckhoff |
| Part Number / Model | CP6732-0000-0060 |
| Device Type | Built-in Panel PC |
| Display Size | 15-inch |
| Display Resolution | 1024 x 768 pixels |
| Touch Screen Technology | Single-finger touch |
| Processor Options | Intel Atom x5-E3930 (1.3 GHz, 2 cores) or Intel Atom x5-E3940 (1.6 GHz, 4 cores) |
| System Memory | 4 GB DDR4 RAM (upgradable up to 8 GB DDR4 RAM ex factory) |
| Storage Interface | 1 x slot for CFast |
| Ethernet Interfaces | 2 x 100/1000BASE-T on-board ports |
| USB Interfaces | 2 x USB 3.0, 2 x USB 2.0 |
| Video Output | 1 x DVI |
| Input Voltage | 24 V DC |
| Operating Temperature | 0 to 55 degC |
| Ingress Protection Rating | Front side IP65, rear side IP20 |
| Weight | 8.0 kg (Shipping weight) |
During installation, mount the unit within a suitable cutout in a control cabinet door or panel. Secure the Panel PC in place using the integrated pull-out clamping levers to guarantee uniform sealing against the mounting surface. Maintain a free ventilation space of at least 50 mm above and below the PC to facilitate convective cooling, ensuring the ambient temperature within the cabinet does not exceed 55 degC. Establish a low-impedance ground connection to the chassis grounding point to minimize electromagnetic interference (EMI) and safeguard communication interfaces.
