Industrial automation setups requiring high-performance processing utilize the CX1030-0112 basic CPU module as a central control unit within the Beckhoff Embedded PC system. This module features an Intel Pentium M processor running at 1.8 GHz, delivering considerable computing power for demanding PLC, NC PTP, or NC I motion control applications. Configured with a internal 16-bit ISA (PC/104) system bus, the module maintains robust communication capabilities with adjacent system expansion terminals.
The unit acts as the core controller, relying on compatible CX1100 power supply modules to interface with either E-bus or K-bus I/O terminal systems. Network communications are facilitated via two RJ45 ports connected through an internal switch, enabling simple daisy-chain networking topologies without external switches. To ensure operational stability under high thermal loads, the processor is fitted with an active cooling module consisting of a speed-controlled, double ball bearing fan cartridge that can be easily replaced in the field.
| Parameter | Specification |
|---|---|
| Manufacturer | Beckhoff |
| Model / Article Number | CX1030-0112 |
| Processor | Intel Pentium M, 1.8 GHz |
| Number of Cores | 1 |
| Flash Memory | Compact Flash slot (128 MB CF card included) |
| Main Memory | 256 MB DDR RAM (expandable ex factory to 1 GB) |
| Network Interfaces | 2 x RJ45 10/100 Mbit/s (internal switch) |
| System Bus | 16-bit ISA (PC/104) |
| I/O Connection Type | Via CX1100 power supply module (E-bus, K-bus, or K-bus/IP-Link) |
| Diagnostic LEDs | 1 x Power, 2 x LAN link/activity, 1 x TC status, 1 x Flash access |
| Cooling | Active cooling module with speed-controlled fan cartridge |
| Real-Time Clock | Internal battery-backed clock (exchangeable battery) |
| Max. Power Consumption | 32 W |
| Dimensions (W x H x D) | 96 mm x 112 mm x 99 mm |
| Weight | approx. 580 g |
| Operating Temperature | 0 to 50 degC |
| Storage Temperature | -25 to 85 degC |
| Relative Humidity | 95 %, non-condensing |
| Protection Rating | IP20 |
| Interface / Port | Function |
|---|---|
| RJ45 (Port 1 & Port 2) | 10/100 Mbit/s Ethernet interface via internal switch |
| CF Slot | Compact Flash Type I + II insert with eject mechanism for OS and user programs |
| PC/104 Bus | 16-bit internal system bus connection for expansion modules |
