The EK1310 (EK1310) serves as a critical bridge within the Beckhoff EtherCAT P ecosystem, designed to convert standard E-bus signals into 100BASE-TX Ethernet for seamless feed-in into an EtherCAT P network. By integrating this module, you can extend your EtherCAT network while simultaneously injecting auxiliary power (US and UP) directly into the EtherCAT P line. This consolidated approach reduces cabinet wiring complexity by combining communication and power distribution into a single, shielded EtherCAT P cable, making it an ideal solution for decentralized I/O segments and machine-mounted automation components.
The EK1310 is housed in a compact, IP20-rated polycarbonate enclosure designed for standard 35 mm DIN rail installation. It features an M8 P-coded interface, which ensures reliable, high-speed data transfer while maintaining the physical separation of power and signal paths required by the EtherCAT P standard. The unit supports a robust external feed-in of 24 V DC for both system (US) and peripheral (UP) voltages, with a total current capacity of 3 A per voltage path. Its integrated electrical isolation (500 V) ensures protection against electrical noise and ground loops, essential for maintaining stable network performance in complex industrial environments.
| Feature | Specification |
| Model | EK1310 |
| Brand | Beckhoff |
| Function | EtherCAT to EtherCAT P conversion |
| Interface | 1 x M8 P-coded socket |
| Current Rating | Max. 3 A (US and UP) |
| System Supply | 24 V DC |
| Weight | Approx. 165 g |
| Dimensions | 44 mm x 100 mm x 68 mm |
| Protection Class | IP20 |
| Operating Temp | 0 deg C to 55 deg C |
What is the main benefit of converting to EtherCAT P?
EtherCAT P combines both communication and power into a single cable, which simplifies installation, reduces cable clutter, and decreases the time required for machine commissioning.
Can the EK1310 handle high-power peripheral loads?
The module supports up to 3 A per voltage path (US and UP). Ensure your total peripheral load does not exceed this 3 A limit to prevent thermal shutdown of the port.
Why is the interface P-coded?
The P-coding on the M8 connector is a specific standard for EtherCAT P to prevent the accidental connection of standard Ethernet or non-power-carrying M8 cables, ensuring safety and protecting the communication hardware.
Is this module suitable for field-level installation?
The EK1310 is rated IP20 and is designed for use within protected control cabinets. If you require EtherCAT P distribution at the machine level, please consider the IP67-rated EtherCAT Box versions.
Cable Integrity: Use only high-quality, shielded EtherCAT P cables. Ensure that the shield is properly terminated according to EtherCAT P standards to maintain signal integrity and meet EMC requirements.
Terminal Mounting: The EK1310 supports side-by-side mounting using the double slot and key connection. Ensure all modules are firmly snapped onto the DIN rail to guarantee the internal K-bus communication between adjacent terminals.
Power Feed Safety: When connecting the 24 V DC supply, verify polarity before powering up. Although the module is designed for robust industrial use, improper power feed can lead to communication loss or hardware damage.
Global Express Shipping
Returns & Warranty
Manufacturer: BECKHOFF
Product No.: EK1310
Country of origin:Germany
Product Type: EtherCAT P Extension
Payment: T/T, Western Union
Weight: 5000g
Dimensions: 44 mm x 100 mm x 68 mm
Shipping port: Xiamen
Warranty: 12 months
