Description

16925-17 is a 3-conductor shielded 22 AWG (0.5 mm2) interconnect cable designed for the 330400 and 330425 series accelerometer systems. This configuration specifies a 5.0 meter cable length, featuring a 3-socket plug at the transducer end and terminal lugs for instrumentation connection at the opposite end. This cable is used to transmit casing vibration signals from the accelerometer to the monitoring instrumentation. It provides a reliable signal path for critical machinery monitoring applications, including gear mesh monitoring and overall machine protection. The assembly is built for standard installation environments, typically routed within protected conduits or enclosures.

Features

• 3-socket plug connector for 330400 and 330425 accelerometer interface
• 3-conductor shielded 22 AWG (0.5 mm2) construction
• 5.0 meter (16.4 ft) cable length (Option 17)
• Terminal lug termination for easy instrumentation panel connection
• Designed for critical machinery casing acceleration measurements

Applications

• Critical machinery vibration monitoring
• Gear mesh monitoring
• Casing acceleration measurements
• Rotating machinery protection

Ordering Information

Orderable Part Number	16925-17	330400 / 330425 Interconnect Cable
Cable Length Option	17	5.0 meters (16.4 ft)

Technical Specifications

Manufacturer	Bently Nevada
Part Number	16925-17
Cable Type	3-conductor shielded, 22 AWG (0.5 mm2)
Connector (Transducer End)	3-socket plug
Connector (Field End)	Terminal lugs
Length	5.0 meters (16.4 ft)
Conductor Size	22 AWG (0.5 mm2)

Installation Guidelines

Standard installation requires the cable to be routed in protective conduit or enclosures to prevent mechanical damage or environmental exposure. Ensure the 3-socket plug is properly seated on the accelerometer. The terminal lugs should be securely terminated in the instrumentation junction box or terminal block as specified by the system wiring diagram.

Compliance and Certifications

• RoHS Directive 2011/65/EU
• EMC Directive 2014/30/EU
