Bently Nevada 330400-02-05 Accelerometer

SKU 330400-02-05

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330400-02-05
Origin United States
Product Type: Accelerometer
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.1 kg
Dimensions: 2.8cm x 8.1cm x 9.9cm
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantità

Call sales Contact

Product Description

Description

The 330400-02-05 is a high-precision acceleration transducer designed for critical machinery monitoring applications, such as gear mesh analysis and casing vibration measurement. This configuration features an M8 x 1 integral mounting stud (Option 02) and includes multiple agency approvals (Option 05), including CSA, ATEX, and IECEx certifications for use in hazardous environments.

Engineered to meet the requirements of the American Petroleum Institute (API) Standard 670, this accelerometer delivers a sensitivity of 100 mV/g with an amplitude range of 50 g peak. The 330400 series provides consistent performance in demanding industrial settings, with a wide frequency response range of 10 Hz to 15 kHz. Its hermetically sealed, 316L stainless steel case ensures reliability in harsh, condensing, and non-submerged environments.

Features

Option 02: M8 x 1 integral mounting stud for secure installation
Option 05: Certified for hazardous area use (CSA, ATEX, IECEx)
Sensitivity: 100 mV/g (10.2 mV/m/s2)
Amplitude Range: 50 g peak (490 m/s2)
Frequency Response: 10 Hz to 15 kHz
Operating Temperature: -55 degC to +121 degC
Connector: 3-pin MIL-C-5015 receptacle
Case Material: 316L stainless steel

Applications

Critical machinery protection
Gear mesh monitoring
Casing vibration measurements
Rotating machinery analysis (unbalance, misalignment detection)
Oil and gas, petrochemical, and power generation monitoring

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330400-02-05	330400 Accelerometer
A - Mounting Thread	02	M8 x 1 integral stud
B - Agency Approval	05	Multiple approvals (CSA, ATEX, IECEx)

Technical Specifications

Manufacturer	Bently Nevada (Baker Hughes)
Part Number	330400-02-05
Sensitivity	100 mV/g (10.2 mV/m/s2)
Acceleration Range	50 g peak (490 m/s2)
Frequency Response	10 Hz to 15 kHz
Operating Temperature	-55 degC to +121 degC
Case Material	316L stainless steel
Connector	3-pin MIL-C-5015
Weight	100 g (typical, no cable)
Mounting Torque	4.1 N-m (3.0 ft-lb)
IP Rating	IP68 (sensor only)

Installation Guidelines

Mount the accelerometer on the bearing housing or machine casing for effective vibration transmission.
Ensure the mounting surface is 32 microinch rms finish.
Tighten mounting stud to a torque of 4.1 N-m (3.0 ft-lb).
For hazardous areas, ensure installation complies with the provided entity parameters and local electrical codes (e.g., CSA, ATEX, IECEx).
Use appropriate conduit and cabling to protect the connector and cable assembly.

Compliance and Certifications

CSA (Class I, Div 1/2; Class II; Class III)
ATEX / IECEx (Ex ia IIC T3 Ga / Ex ec IIC Gc)
CE
RoHS
ABS Marine Vessels compliant

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What does the 02 option code represent for this 330400 accelerometer?

The 02 option code indicates an M8 x 1 integral mounting stud for the sensor housing.

Is this sensor certified for hazardous areas?

Yes, the 05 option code signifies that this unit includes multiple hazardous area approvals, including CSA, ATEX, and IECEx certifications.

What is the sensitivity of the 330400-02-05 accelerometer?

This unit has a nominal sensitivity of 100 mV/g (10.2 mV/m/s2).

Can this accelerometer be used for gear mesh monitoring?

Yes, the 330400 series is specifically designed for critical machinery applications, including gear mesh monitoring and overall casing acceleration measurements.
