084G2207

Danfoss

Danfoss 084G2207 EMP 2-1811-F6CD25-2 Pressure Transmitter

SKU 084G2207

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Danfoss
  • Product No.: 084G2207
  • Origin United States
  • Product Type: Pressure Transmitter
  • Payment: T/T, Western Union
  • Weight: 2.5 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

EMP Pressure Transmitters
Quantità
Call sales Contact

Product Description

The Danfoss 084G2207 is a precision-engineered Pressure Transmitter from the EMP series, designed to provide accurate and reliable pressure measurement in industrial automation and process control systems. This device translates pressure into a standardized 4–20 mA current signal, ensuring compatibility with modern PLC, DCS, and SCADA monitoring platforms.

Features

  • High Accuracy: Offers a 0.5% typical (1% max) Full Scale accuracy with 0.3% BFSL non-linearity.
  • Fast Response: Capable of a 4 ms maximum response time for dynamic process requirements.
  • Robust Design: Housed in an IP65-rated enclosure suitable for harsh industrial environments.
  • Diagnostics: Features internal clipping levels (3.6 mA low / 22.4 mA high) for system fault detection.
  • Connectivity: Equipped with a standard G 3/8 male pressure connection (EN 837) for secure integration into existing hydraulic or pneumatic lines.

Applications

  • Industrial machinery and factory automation
  • Hydraulic power units and pneumatic systems
  • Pump and compressor monitoring
  • HVAC and cooling/heating process management

Technical Specifications

Parameter Specification
Manufacturer Danfoss
Model / Spec Key EMP 2-1811-F6CD25-2
Product No. 084G2207
Pressure Range 0 to 6 bar (0 to 87.02 psi)
Output Signal 4 to 20 mA (Current)
Supply Voltage 12 to 32 V DC
Overload Pressure 18 bar (max)
Non-linearity (BFSL) 0.3 % FS
Medium Temp. Range -10 to 70 degC
Enclosure Rating IP65
Pressure Connection G 3/8 A (EN 837)
Electrical Connection Terminal block (Pg 13.5)
Shipping Weight 2.5 Kg

Connections/Interfaces

Connector Pin Function
P Supply Voltage (+)
N Common / Signal Ground (-)

Installation Guidelines

  • Mounting: Install the transmitter in an upright or horizontal position. Ensure the process connection is tightened to the correct torque using appropriate sealing washers to prevent leaks.
  • Wiring: Use high-quality shielded twisted-pair cabling for the 4–20 mA output. Secure the Pg 13.5 cable gland firmly to maintain the IP65 enclosure integrity against dust and moisture.
  • EMI/RFI Mitigation: Maintain physical separation between the transmitter signal cabling and high-voltage power lines or variable frequency drive (VFD) cables to prevent electromagnetic interference.
  • Calibration: While factory-calibrated, ensure that the PLC input channel is properly scaled to match the 0–6 bar range for accurate monitoring.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the pressure measurement range for the 084G2207?
This transmitter is designed for a pressure range of 0 to 6 bar (0 to 87.02 psi).
What is the significance of the clipping levels on this device?
The low (3.6 mA) and high (22.4 mA) clipping levels allow the control system to detect if the sensor signal is out of normal operating range, indicating a potential fault or short circuit.
Does this model require specific power supply requirements?
It operates on a DC supply voltage between 12 V and 32 V.
What is the maximum overload pressure this transmitter can withstand?
The maximum overload pressure for this specific model is 18 bar.
Reviews

More from this brand

Danfoss 132L6122 iC2-30 Frequency Converter 5.5 kW
132L6122Danfoss 132L6122 iC2-30 Frequency Converter 5.5 kW
132L6123 | Danfoss | iC2-30 Frequency Converter Air Cooled
132L6123132L6123 | Danfoss | iC2-30 Frequency Converter Air Cooled
Danfoss 080G5400 EKE 1C Superheat Controller
080G5400Danfoss 080G5400 EKE 1C Superheat Controller
Danfoss 061B010266 Bellows Type Pressure Switch
061B010266Danfoss 061B010266 Bellows Type Pressure Switch

084G2207

Stock & lead time on request

Call
  • 084G2207
1 1

Danfoss 084G2207 EMP 2-1811-F6CD25-2 Pressure Transmitter

Only 10 item(s) left in stock

  • Manufacturer: Danfoss

  • Product No.: 084G2207

  • Country of origin:United States

  • Product Type: Pressure Transmitter

  • Payment: T/T, Western Union

  • Weight: 2500g

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

The Danfoss 084G2207 is a precision-engineered Pressure Transmitter from the EMP series, designed to provide accurate and reliable pressure measurement in industrial automation and process control systems. This device translates pressure into a standardized 4–20 mA current signal, ensuring compatibility with modern PLC, DCS, and SCADA monitoring platforms.

Features

  • High Accuracy: Offers a 0.5% typical (1% max) Full Scale accuracy with 0.3% BFSL non-linearity.
  • Fast Response: Capable of a 4 ms maximum response time for dynamic process requirements.
  • Robust Design: Housed in an IP65-rated enclosure suitable for harsh industrial environments.
  • Diagnostics: Features internal clipping levels (3.6 mA low / 22.4 mA high) for system fault detection.
  • Connectivity: Equipped with a standard G 3/8 male pressure connection (EN 837) for secure integration into existing hydraulic or pneumatic lines.

Applications

  • Industrial machinery and factory automation
  • Hydraulic power units and pneumatic systems
  • Pump and compressor monitoring
  • HVAC and cooling/heating process management

Technical Specifications

Parameter Specification
Manufacturer Danfoss
Model / Spec Key EMP 2-1811-F6CD25-2
Product No. 084G2207
Pressure Range 0 to 6 bar (0 to 87.02 psi)
Output Signal 4 to 20 mA (Current)
Supply Voltage 12 to 32 V DC
Overload Pressure 18 bar (max)
Non-linearity (BFSL) 0.3 % FS
Medium Temp. Range -10 to 70 degC
Enclosure Rating IP65
Pressure Connection G 3/8 A (EN 837)
Electrical Connection Terminal block (Pg 13.5)
Shipping Weight 2.5 Kg

Connections/Interfaces

Connector Pin Function
P Supply Voltage (+)
N Common / Signal Ground (-)

Installation Guidelines

  • Mounting: Install the transmitter in an upright or horizontal position. Ensure the process connection is tightened to the correct torque using appropriate sealing washers to prevent leaks.
  • Wiring: Use high-quality shielded twisted-pair cabling for the 4–20 mA output. Secure the Pg 13.5 cable gland firmly to maintain the IP65 enclosure integrity against dust and moisture.
  • EMI/RFI Mitigation: Maintain physical separation between the transmitter signal cabling and high-voltage power lines or variable frequency drive (VFD) cables to prevent electromagnetic interference.
  • Calibration: While factory-calibrated, ensure that the PLC input channel is properly scaled to match the 0–6 bar range for accurate monitoring.
Key Features:
#EMP #Pressure Transmitters

What is the pressure measurement range for the 084G2207?
This transmitter is designed for a pressure range of 0 to 6 bar (0 to 87.02 psi).

What is the significance of the clipping levels on this device?
The low (3.6 mA) and high (22.4 mA) clipping levels allow the control system to detect if the sensor signal is out of normal operating range, indicating a potential fault or short circuit.

Does this model require specific power supply requirements?
It operates on a DC supply voltage between 12 V and 32 V.

What is the maximum overload pressure this transmitter can withstand?
The maximum overload pressure for this specific model is 18 bar.

Global Express Shipping

  • Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).


For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
