Danfoss 134F2981 FC-360H15KT4E20H2BXCDXXSXXXXAXBX VLT AutomationDrive Frequency Converter

SKU 134F2981

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Danfoss
Product No.: 134F2981
Origin United States
Product Type: Variable Frequency Drive
Payment: T/T, Western Union
Weight: 7.75 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The Danfoss 134F2981 is a VLT AutomationDrive FC-360 series frequency converter designed for high-performance motor control in industrial applications. This 15 kW (20 HP) drive operates on a 380-480VAC three-phase supply and is configured with an integrated brake chopper for dynamic braking requirements. Featuring an IP20/Chassis enclosure and an integrated RFI Class A2 filter, this unit ensures reliable operation in cabinet-mounted environments. The device includes a coated PCB for enhanced protection against harsh industrial atmospheres and supports loadsharing functionality for energy-efficient system integration.

Features

Rated Power: 15 kW / 20 HP
Input Voltage: 380-480 VAC, 3-phase
Enclosure Rating: IP20 / Chassis
Integrated Brake Chopper: Included (B)
RFI Protection: Class A2 Filter
PCB Protection: Conformal Coated
Mains Option: Loadsharing enabled
Software: Latest standard release

Applications

Conveyor systems and material handling
Pump and fan control
Extruders and mixers
Centrifugal machines
General-purpose industrial automation

Technical Specifications

Feature	Specification
Manufacturer	Danfoss
Product Model	134F2981
Series	VLT AutomationDrive FC-360
Power Rating	15 kW (20 HP)
Supply Voltage	380-480VAC (Three-phase)
Enclosure Type	IP20 / Chassis
RFI Filter	Class A2
Brake Chopper	Included
PCB Coating	Coated
Mains Option	Loadsharing
Weight	7.75 Kg
Shipping Weight	10 Kg

Installation Guidelines

Mounting: Designed for vertical mounting within an electrical enclosure to ensure proper airflow and cooling.
Cooling: Ensure sufficient clearance above and below the unit for heat dissipation, as per the thermal management requirements of the VLT FC-360 series.
Environment: The unit is intended for installation in a pollution-controlled environment; however, the coated PCB provides resistance against corrosive gases.
Wiring: Ensure all cable entries are properly secured. Use shielded motor cables to maintain compliance with RFI Class A2 standards.
Grounding: Maintain a low-impedance ground connection to the cabinet chassis to ensure effective EMI/RFI mitigation.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the brake chopper in this drive?

The integrated brake chopper allows the drive to dissipate excess energy generated by the motor during deceleration or overhauling loads by connecting to an external braking resistor.

Does this model include a control panel?

No, the 134F2981 is supplied without a display or blind cover (X - No Display).

What is the benefit of the coated PCB option?

The conformal coating provides an additional layer of protection against moisture, dust, and corrosive industrial chemicals, extending the operational life of the control board in harsh environments.

Can this drive be used in loadsharing configurations?

Yes, this specific configuration includes the loadsharing option (D), allowing the DC bus to be shared with other drives to optimize energy consumption.
