General Electric IS200VSVOH1BDC Mark VI Servo Control Card

SKU IS200VSVOH1BDC

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: General Electric
  • Product No.: IS200VSVOH1BDC
  • Origin United States
  • Product Type: Servo Control Cards
  • Payment: T/T, Western Union
  • Weight: 0.45 kg
  • Dimensions: 25.4 mm x 178.0 mm x 304.8 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Mark VI Servo Control Cards
Quantità
Call sales Contact

Product Description

Description

The General Electric IS200VSVOH1BDC is a servo control card designed for servo valve interface applications in Mark VI turbine control systems. The board processes signals for driving servo valves and interfacing pulse rate inputs for flow divider feedback within servo control loops. Operating within steam and gas turbine assemblies, it interfaces with both active and passive speed sensors to deliver precise signal feedback. The unit utilizes standard bi-directional servo current outputs and supports configurations with 2 or 3 coil servos to meet specific redundancy requirements.

Features

  • Supports servo valve interface I/Os and pulse rate inputs ranging from 2 to 14k Hz
  • Handles flow divider feedback signals within specialized servo control loops
  • Interfaces with active or passive speed sensors, including up to two additional passive sensors when paired with a Backup Protection Module
  • Accommodates 2 or 3 coil servos for redundant configurations, including TMR applications
  • Features 4 servo channels, each supporting up to 3 LVDT or LVDR feedback sensors with median, high, or low selection via software
  • Includes 3 onboard diagnostic LEDs for Run, Fail, and Status indication
  • Provides bi-directional servo current outputs for system control

Applications

  • Mark VI turbine control system drive assemblies
  • Steam turbine servo valve control
  • Gas turbine flow divider feedback systems
  • Redundant Triple Modular Redundant (TMR) turbine protection loops

Technical Specifications

Category Parameter Specification
Mechanical Functional Part Number IS200VSVOH1BDC
Mechanical Revisions BDC
Mechanical Functional Acronym/Abbreviation VSVO
Manufacturer Manufacturer GE Industrial Systems, General Electric Company US
Functional Functional Description Servo Control Card
Functional Prime Mover Type Steam or Gas Turbines
Input/Output Application Specific I/O Servo Valve Interface
Input/Output Coil Servo Quantity 2 or 3; 3 for TMR Applications
Input/Output Frequency Range for Pulse Rate Inputs 2-14k Hz
Input/Output Speed Sensor Compatibility Active or Passive
Performance Sensitivity Range 2 Hz
Performance Servo Channels 4 channels; up to 3 LVDT/LVDR sensors per channel
Performance Servo Current Output Type Bi-directional
Visual Indicators LED Quantity 3; Run, Fail, Status
