HIMA Z1006 Circuit Board Assembly

SKU Z1006

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: HIMA
Product No.: Z1006
Origin Germany
Product Type: Circuit Board
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.7 kg
Dimensions: 43cm x 12.8cm x 4cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The HIMA Z1006 is an industrial circuit board assembly (Platine) developed for legacy safety-related automation frameworks. Functioning as an internal sub-assembly or interface unit, this hardware board coordinates circuit connections and preserves systemic signal flow across specialized safety control systems. Built with robust logic gating traces, the module features Version C architecture revision under factory identification layout 157528-1. This obsolete module serves as a crucial maintenance component for expanding or maintaining operating lifespans of critical industrial protection systems without modifying established backplane networks.

Features

High-grade industrial Version C design revisions for optimized circuit routing
Heavy-duty multi-contact board connection interface pins for backplane mating
Serves as an exact physical sub-assembly replacement for legacy safety platforms
Standardized design layout matching exact OEM specification dimensions

Applications

System maintenance and servicing of legacy safety controller racks
Critical safety loop signal distribution
Industrial factory automation panel retrofits

Technical Specifications

Parameter	Value
Manufacturer	HIMA Paul Hildebrandt GmbH + Co KG
Model Designation	Z1006
Hardware Revision	Version C
Factory Board Number	157528-1
Component Type	Circuit Board Assembly (Platine)
Country of Origin	Germany

Installation Guidelines

ESD Mitigation: Use a calibrated static discharge wrist strap attached to a verified grounding point before handling the circuit board.
Slot Alignment: Carefully orient the board within the chassis guides to align the contact pins with the mating backplane sockets, pressing evenly to secure the interface.
Fastener Security: Tighten any integrated faceplate or sub-panel retention screws completely to safeguard against industrial mechanical shocks.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the function of the hardware layout number 157528-1?

The number 157528-1 is the factory-designated circuit board number used to verify correct sub-assembly design and physical configuration matching.

Is this specific hardware board version backward compatible?

Yes, this Version C module is engineered to provide direct mechanical and electrical compatibility with legacy chassis slots utilizing the Z1006 footprint.

What precautions should be applied during the mechanical handling of this component?

Standard electrostatic discharge protection guidelines must be executed, ensuring the card is only handled in an ESD-protected zone to shield the delicate board traces.
