Description

The LXM28AUA5M3X is a compact servo drive from the Schneider Electric Lexium 28 range, engineered for high-precision motion control applications. This drive is designed to operate on either a single-phase or three-phase power supply (200/230 V), providing a versatile solution for systems requiring 50 W of power. As part of the active Lexium 28 series, it is well-suited for modern automation tasks where space-saving design and reliable performance are critical.

Features

• Compatible with single-phase and three-phase power supplies (200/230 V)
• Compact power rating of 50 W
• Part of the active Lexium 28 series for high-precision motion control
• Optimized for ease of integration into varied industrial machinery
• High reliability for demanding positioning applications

Technical Specifications

Installation Guidelines

• Mounting: Ensure the drive is mounted vertically in an enclosure to allow for proper natural convection cooling. Maintain the minimum clearance distances specified in the product manual to avoid thermal tripping.
• Grounding: To comply with EMC standards and ensure safe operation, the drive chassis must be connected to a high-quality protective earth (PE) terminal.
• Wiring: Use shielded twisted-pair cables for encoder and control signal wiring to prevent electrical noise interference. Separate power and signal cable paths within the cable tray.
• Configuration: Utilize the Lexium 28 software tools for initial parameterization. Verify that the motor nameplate data matches the drive configuration before enabling the power stage.

Compliance and Certifications

• Commodity Code: 85044095
• Export Control Regulations (ECCN): N
