Description

Engineered for high-demand industrial automation systems, the Mitsubishi Electric FR-A840-45K-1 is a high-performance variable frequency inverter belonging to the premium FR-A800 series. This drive provides precise speed and torque control for three-phase asynchronous and permanent magnet motors up to 45 kW. Equipped with an FM-type monitor terminal, it allows for analog output monitoring of critical operating parameters. Integrated RS-485, RS-422, and RS-232 communication interfaces enable seamless integration into modern factory networks, ensuring rapid response times and comprehensive diagnostics.

Features

• Designed for heavy-duty applications requiring high startup torque and exceptional speed accuracy.
• Built-in FM monitor terminal for precise analog signal monitoring of system status.
• Supports multiple motor control topologies, including Real Sensorless Vector control and PM sensorless vector control.
• Integrated RS-485/422/232 serial communication ports for direct PLC and HMI connection.
• Robust thermal management system to ensure continuous operation in demanding environments.
• Comprehensive protective features covering overcurrent, overvoltage, and thermal overload.

Applications

• High-capacity pumps and industrial ventilation fans
• Conveyor systems and material handling machinery
• Extruders, mixers, and industrial centrifuges
• Compressor control and cooling systems
• Metalworking and textile processing machinery

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mounting: Install the drive vertically on a flat, non-flammable surface to optimize heat dissipation.
• Clearance: Maintain a minimum clearance of 100 mm above and below the unit, and 50 mm on both sides for adequate ventilation.
• Grounding: Ensure the ground terminal is securely connected to a dedicated industrial earth ground to minimize electromagnetic interference (EMI).
• Wiring: Route control signal cables and power cables through separate conduits to prevent signal degradation. Use shielded cables for control signals and encoder feedback.
• Operating Environment: Install in an environment free from corrosive gases, oil mist, and excessive dust, with ambient temperatures maintained within the rated limits without condensation.

Compliance and Certifications

• CE Mark (Low Voltage and EMC Directives)
• UL Listed / cUL Listed (US and Canadian safety standards)
• RoHS compliant
