Engineered for optimized fluid control and fan applications, the FR-F840-00470-2-60 functions as a high-efficiency variable frequency drive (VFD) within the Mitsubishi Electric FR-F800 family. This energy-saving inverter is tailored for heavy-duty industrial systems, offering precise speed control and advanced motor tuning capabilities to minimize energy consumption in pump, compressor, and HVAC applications.
The unit features a dual-rating structure, allowing engineers to configure the device for Super Light Duty (SLD) or Light Duty (LD) operation depending on system load profiles. Built-in mechanisms handle significant input voltage fluctuations, securing operational continuity in environments with unstable grid infrastructure. Comprehensive protection circuits guard against overload conditions, assuring maximum uptime for critical mechanical operations.
| Manufacturer | Mitsubishi Electric |
|---|---|
| Part Number / Model | FR-F840-00470-2-60 |
| Series | FR-F800 Series |
| Product Type | Energy-Saving Inverter |
| Applicable Motor Capacity (SLD) | 22 kW |
| Input Voltage / Phase | Three-phase 380 to 500 V AC |
| Permissible AC Voltage Fluctuation | 323 to 550 V AC |
| Input Frequency | 50 Hz / 60 Hz |
| SLD Overload Current Rating | 110% for 60 seconds, 120% for 3 seconds (inverse-time characteristics) at surrounding air temperature 40 degC |
| LD Overload Current Rating | 120% for 60 seconds, 150% for 3 seconds (inverse-time characteristics) at surrounding air temperature 50 degC |
| Dimensions (W x H x D) | 250 mm x 400 mm x 190 mm |
| Net Weight | 15 kg |
| Shipping Weight | 17 kg |
Mount the inverter vertically on a flat, non-flammable surface to facilitate optimal heat dissipation. Ensure a minimum clearance above, below, and to the sides of the chassis to allow unobstructed airflow from the internal cooling fans. All power wiring must use appropriately sized, shielded cables to suppress electromagnetic interference (EMI). Ground the unit via a low-impedance ground terminal directly to the main system backplane to ensure electrical safety and noise mitigation.
Global Express Shipping
Returns & Warranty
Manufacturer: Mitsubishi Electric
Product No.: FR-F840-00470-2-60
Country of origin:United States
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 17000g
Dimensions: 250 mm x 400 mm x 190 mm
Shipping port: Xiamen
Warranty: 12 months
Engineered for optimized fluid control and fan applications, the FR-F840-00470-2-60 functions as a high-efficiency variable frequency drive (VFD) within the Mitsubishi Electric FR-F800 family. This energy-saving inverter is tailored for heavy-duty industrial systems, offering precise speed control and advanced motor tuning capabilities to minimize energy consumption in pump, compressor, and HVAC applications.
The unit features a dual-rating structure, allowing engineers to configure the device for Super Light Duty (SLD) or Light Duty (LD) operation depending on system load profiles. Built-in mechanisms handle significant input voltage fluctuations, securing operational continuity in environments with unstable grid infrastructure. Comprehensive protection circuits guard against overload conditions, assuring maximum uptime for critical mechanical operations.
| Manufacturer | Mitsubishi Electric |
|---|---|
| Part Number / Model | FR-F840-00470-2-60 |
| Series | FR-F800 Series |
| Product Type | Energy-Saving Inverter |
| Applicable Motor Capacity (SLD) | 22 kW |
| Input Voltage / Phase | Three-phase 380 to 500 V AC |
| Permissible AC Voltage Fluctuation | 323 to 550 V AC |
| Input Frequency | 50 Hz / 60 Hz |
| SLD Overload Current Rating | 110% for 60 seconds, 120% for 3 seconds (inverse-time characteristics) at surrounding air temperature 40 degC |
| LD Overload Current Rating | 120% for 60 seconds, 150% for 3 seconds (inverse-time characteristics) at surrounding air temperature 50 degC |
| Dimensions (W x H x D) | 250 mm x 400 mm x 190 mm |
| Net Weight | 15 kg |
| Shipping Weight | 17 kg |
Mount the inverter vertically on a flat, non-flammable surface to facilitate optimal heat dissipation. Ensure a minimum clearance above, below, and to the sides of the chassis to allow unobstructed airflow from the internal cooling fans. All power wiring must use appropriately sized, shielded cables to suppress electromagnetic interference (EMI). Ground the unit via a low-impedance ground terminal directly to the main system backplane to ensure electrical safety and noise mitigation.
Global Express Shipping
Returns & Warranty
Orders are processed and delivered Monday-Friday (excluding public holidays).
For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
| Country of origin |
United States
|
