Mitsubishi Electric FX5U-64MT/DS MELSEC iQ-F Series CPU Module

SKU FX5U-64MT/DS

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: FX5U-64MT/DS
  • Origin United States
  • Product Type: CPU Modules
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

CPU Modules MELSEC iQ-F Series
Quantità
Call sales Contact

Product Description

Description

Designed for high-performance industrial automation, the FX5U-64MT/DS serves as a central processing unit within the Mitsubishi Electric MELSEC iQ-F Series. This controller integrates advanced processing capabilities, built-in Ethernet, analog I/O, and high-speed positioning controls into a compact form factor. It manages up to 64 local I/O points (32 inputs and 32 outputs) and supports expansion options to scale with complex machinery requirements. The module features high-speed execution times, making it suitable for demanding applications requiring precise timing and synchronization.

Features

  • High-speed program execution of 0.034 microseconds per basic instruction.
  • Built-in Ethernet port for network communication, programming, and monitoring.
  • Built-in RS-485 port supporting Modbus RTU and proprietary protocols.
  • Integrated SD card slot for data logging, program backups, and system updates.
  • Built-in analog inputs and outputs for direct sensor and actuator interfacing.
  • High-speed counter inputs and pulse outputs for multi-axis positioning control.
  • Screw terminal block connections for secure and reliable field wiring.

Applications

  • Packaging and labeling machinery
  • Material handling and conveyor systems
  • Water and wastewater treatment facilities
  • Food and beverage processing lines
  • HVAC and environmental control systems
  • Assembly and test bench automation

Technical Specifications

Parameter Specification
Manufacturer Mitsubishi Electric
Part Number/Model FX5U-64MT/DS
Series MELSEC iQ-F Series
Module Type CPU Module
Total I/O Points 64 points
Number of Inputs 32 points
Number of Outputs 32 points
Input Type 24 V DC (Sink/Source)
Output Type Transistor (Sink)
Power Supply Voltage 24 V DC
5 V DC Power Supply Capacity 1100 mA
24 V DC Power Supply Capacity 740 mA
Connection Type Screw terminal block
Operating Temperature 0 to 55 degC
Storage Temperature -25 to 75 degC
Shipping Weight 2 kg

Connections and Interfaces

Interface Port Connection Type Functionality
Ethernet RJ45 Connector Programming, MC Protocol, Modbus/TCP, and CC-Link IE Field Basic
RS-485 Terminal Block Serial communication, Modbus RTU, and inverter communication
SD Card Slot Standard SD Slot Data logging, parameter storage, and firmware updates
I/O Terminals Screw Terminals Direct connection for digital inputs, outputs, and analog signals

Installation Guidelines

  • Mounting: Mount securely on a 35mm DIN rail or use direct screw mounting in a clean, dry control cabinet.
  • Grounding: Ensure a dedicated Class D grounding (grounding resistance of 100 ohms or less) using a minimum 2 mm² wire. Do not share grounding wires with high-power equipment.
  • Clearance: Maintain a minimum clearance of 50 mm above and below the module to allow for natural convection cooling and routing of cables.
  • Wiring: Route low-voltage DC signal lines and communication cables separately from high-voltage AC power lines to prevent electromagnetic interference.

Compliance and Certifications

  • CE
  • UL / cUL
  • KC (Korean Certification)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the power supply requirement for the FX5U-64MT/DS?
The FX5U-64MT/DS requires a 24 V DC power supply to operate.
How many physical I/O points are integrated into this CPU module?
The module features 64 built-in I/O points, consisting of 32 digital inputs (24 V DC sink/source) and 32 transistor outputs (sink).
Does the FX5U-64MT/DS support analog inputs and outputs?
Yes, the MELSEC iQ-F FX5U CPU modules include built-in analog inputs and outputs for direct analog signal processing without requiring expansion modules.
Reviews

More from this brand

Mitsubishi Electric Q06UDEHCPU MELSEC-Q Series Universal PLC CPU Module
Q06UDHCPUMitsubishi Electric Q06UDEHCPU MELSEC-Q Series Universal PLC CPU Module
Mitsubishi Electric FX3U-128MR/ES-A | FX3U Series Main Unit
FX3U-128MR/ES-AMitsubishi Electric FX3U-128MR/ES-A | FX3U Series Main Unit
Mitsubishi MELSEC MR-J3-40A Servo Amplifier | 400W 3-Phase or 1-Phase 200V
MR-J3-40AMitsubishi MELSEC MR-J3-40A Servo Amplifier | 400W 3-Phase or 1-Phase 200V
Mitsubishi MR-J2S-40A-S004 | 400W AC Servo Amplifier
MR-J2S-40A-S004Mitsubishi MR-J2S-40A-S004 | 400W AC Servo Amplifier

FX5U-64MT/DS

Stock & lead time on request

Call
  • FX5U-64MT/DS
1 1

Mitsubishi Electric FX5U-64MT/DS MELSEC iQ-F Series CPU Module

Only 10 item(s) left in stock

  • Manufacturer: Mitsubishi Electric

  • Product No.: FX5U-64MT/DS

  • Country of origin:United States

  • Product Type: CPU Modules

  • Payment: T/T, Western Union

  • Weight: 2000g

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

Designed for high-performance industrial automation, the FX5U-64MT/DS serves as a central processing unit within the Mitsubishi Electric MELSEC iQ-F Series. This controller integrates advanced processing capabilities, built-in Ethernet, analog I/O, and high-speed positioning controls into a compact form factor. It manages up to 64 local I/O points (32 inputs and 32 outputs) and supports expansion options to scale with complex machinery requirements. The module features high-speed execution times, making it suitable for demanding applications requiring precise timing and synchronization.

Features

  • High-speed program execution of 0.034 microseconds per basic instruction.
  • Built-in Ethernet port for network communication, programming, and monitoring.
  • Built-in RS-485 port supporting Modbus RTU and proprietary protocols.
  • Integrated SD card slot for data logging, program backups, and system updates.
  • Built-in analog inputs and outputs for direct sensor and actuator interfacing.
  • High-speed counter inputs and pulse outputs for multi-axis positioning control.
  • Screw terminal block connections for secure and reliable field wiring.

Applications

  • Packaging and labeling machinery
  • Material handling and conveyor systems
  • Water and wastewater treatment facilities
  • Food and beverage processing lines
  • HVAC and environmental control systems
  • Assembly and test bench automation

Technical Specifications

Parameter Specification
Manufacturer Mitsubishi Electric
Part Number/Model FX5U-64MT/DS
Series MELSEC iQ-F Series
Module Type CPU Module
Total I/O Points 64 points
Number of Inputs 32 points
Number of Outputs 32 points
Input Type 24 V DC (Sink/Source)
Output Type Transistor (Sink)
Power Supply Voltage 24 V DC
5 V DC Power Supply Capacity 1100 mA
24 V DC Power Supply Capacity 740 mA
Connection Type Screw terminal block
Operating Temperature 0 to 55 degC
Storage Temperature -25 to 75 degC
Shipping Weight 2 kg

Connections and Interfaces

Interface Port Connection Type Functionality
Ethernet RJ45 Connector Programming, MC Protocol, Modbus/TCP, and CC-Link IE Field Basic
RS-485 Terminal Block Serial communication, Modbus RTU, and inverter communication
SD Card Slot Standard SD Slot Data logging, parameter storage, and firmware updates
I/O Terminals Screw Terminals Direct connection for digital inputs, outputs, and analog signals

Installation Guidelines

  • Mounting: Mount securely on a 35mm DIN rail or use direct screw mounting in a clean, dry control cabinet.
  • Grounding: Ensure a dedicated Class D grounding (grounding resistance of 100 ohms or less) using a minimum 2 mm² wire. Do not share grounding wires with high-power equipment.
  • Clearance: Maintain a minimum clearance of 50 mm above and below the module to allow for natural convection cooling and routing of cables.
  • Wiring: Route low-voltage DC signal lines and communication cables separately from high-voltage AC power lines to prevent electromagnetic interference.

Compliance and Certifications

  • CE
  • UL / cUL
  • KC (Korean Certification)
Key Features:
#CPU Modules #MELSEC iQ-F Series

What is the power supply requirement for the FX5U-64MT/DS?
The FX5U-64MT/DS requires a 24 V DC power supply to operate.

How many physical I/O points are integrated into this CPU module?
The module features 64 built-in I/O points, consisting of 32 digital inputs (24 V DC sink/source) and 32 transistor outputs (sink).

Does the FX5U-64MT/DS support analog inputs and outputs?
Yes, the MELSEC iQ-F FX5U CPU modules include built-in analog inputs and outputs for direct analog signal processing without requiring expansion modules.

Global Express Shipping

  • Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).


For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
