Description

Designed for robust industrial visualization, the GT1155-QSBD-C serves as a high-performance operator terminal within the Mitsubishi Electric GOT1000 series. This 5.7-inch STN color graphic operation terminal provides clear diagnostic displays and intuitive control interfaces for diverse factory automation environments. Engineered with integrated communication ports, it interfaces directly with MELSEC PLCs and other industrial controllers, ensuring seamless data exchange on the factory floor.

Features

• 5.7-inch STN color liquid crystal display offering clear visual status updates.
• 320 x 240 pixel QVGA resolution optimized for compact HMI screens.
• Analog resistive touch panel allowing flexible custom screen layouts and button assignments.
• Compact mechanical footprint with shallow mounting depth to fit into constrained control panels.
• Built-in serial communication capabilities for direct connection to controllers.

Applications

• Automotive assembly lines and robot cells
• Packaging and labeling machinery
• Water treatment and pumping stations
• Material handling and conveyor systems
• Food and beverage processing lines

Technical Specifications

Installation Guidelines

To ensure stable operation and extend the service life of the GT1155-QSBD-C, please adhere to the following installation practices:

• Maintain a minimum clearance of 100 mm from surrounding equipment and enclosure walls to allow adequate natural convection and cooling.
• Mount the terminal securely in a clean, dust-free environment using the supplied mounting brackets to maintain structural integrity.
• Ensure the functional ground (FG) terminal is connected to a dedicated industrial ground to protect the unit from high-frequency electrical noise.
• Avoid installing the device in areas exposed to direct sunlight, high humidity, or extreme temperature drops.
