Mitsubishi Electric GT1575-VNBD GOT1000 Series Touch Screen HMI

SKU GT1575-VNBD

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Mitsubishi Electric
Product No.: GT1575-VNBD
Origin United States
Product Type: Touch Screen HMIs
Payment: T/T, Western Union
Weight: 2.4 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Designed for robust industrial monitoring and machine control, the GT1575-VNBD serves as a reliable operator terminal within the Mitsubishi Electric GOT1000 platform. This touch screen HMI provides clear graphical visualization and comprehensive system diagnostics directly on the factory floor. Configured with a 10.4-inch display, it enables quick-response touch operations and accommodates dense visual schematics for intricate automation layouts. Incorporating extensive built-in communication interfaces and expansion options, this terminal links seamlessly with PLCs, variable speed drives, and motion controllers.

Features

High-contrast 10.4-inch TFT LCD panel offering clear visualization under varied lighting conditions.
Analog resistive touch screen allowing flexible touch key layouts and dual-point press prevention.
Integrated RS-232 and RS-422/485 interfaces for direct connection to host controllers.
Built-in CF card slot supporting data logging, alarm history collection, and recipe management.
Expandable bus connection system for Ethernet, CC-Link, and Melseclnet communication options.
IP67f ingress protection rating on the front panel when properly mounted.

Applications

Automotive assembly lines and conveyor control.
Packaging, labeling, and filling machinery.
Water treatment and environmental monitoring stations.
Food and beverage thermal processing lines.

Technical Specifications

ManufacturerModel / Part NumberSeriesDisplay TypeScreen SizeResolutionBacklight LifeInput VoltagePower ConsumptionOperating TemperatureStorage TemperatureExternal DimensionsPanel Cutout DimensionsWeight

Mitsubishi Electric

GT1575-VNBD

GOT1000 (GT15)

TFT Color LCD

10.4 inches

640 x 480 dots (VGA)

Approximately 41,000 hours (at an ambient operating temperature of 25 degC)

24V DC (+25%, -20%)

19W or less (with backlight off: 12W or less)

0 to 50 degC

-20 to 60 degC

289 mm (W) x 200 mm (H) x 52 mm (D)

258 mm (W) x 183 mm (H)

Approximately 2.4 kg (excluding mounting brackets)

Connections and Interfaces

Port / Interface	Specification / Connection Type
RS-232	D-sub 9-pin (male), transmission speed up to 115,200 bps
RS-422/485	D-sub 9-pin (female), transmission speed up to 115,200 bps
USB (Device)	1 channel, Mini-B connector for PC communication and program transfer
CF Card Slot	1 slot, Type I compact flash card

Installation Guidelines

Mounting Location: Install the HMI into a flat panel of an industrial enclosure. Ensure the mounting gasket is correctly seated in its groove to maintain sealing integrity.
Torque Limits: Tighten the supplied panel mounting brackets to a torque of 0.36 to 0.48 N-m. Over-tightening may warp the front panel or crack the housing.
Clearance Requirements: Leave at least 100 mm of clearance space behind and around the unit for proper heat dissipation and cable routing.
Grounding: Connect the ground terminal of the HMI power connector to a dedicated functional ground (Class D, ground resistance of 100 ohms or less) using a minimum 2 mm2 gauge wire.

Compliance and Certifications

CE Directive Compliance (EMC and Low Voltage Directives)
UL / cUL Listed (Class I, Division 2, Groups A, B, C, D hazardous locations)
KC (Korean Certification for electromagnetic compatibility)

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary power requirement for the GT1575-VNBD?

The HMI operates on a nominal 24V DC input voltage, with an allowable range of +25% to -20% (19.2V DC to 30V DC).

Can I transfer project files to the GT1575-VNBD using a USB cable?

Yes, the unit features a built-in USB device port (Mini-B) specifically designed for project uploads, downloads, and OS installation via PC software.

What are the recommended mounting cutout dimensions for this HMI?

The required panel cutout dimensions are 258 mm (W) x 183 mm (H) with an acceptable plate thickness of 2 mm to 10 mm.

How do I protect the unit against dust and water entry in harsh environments?

When properly installed using the provided waterproof gasket and mounting brackets, the front panel achieves an IP67f rating, protecting against dust ingress and oil/water spray.
