Engineered for demanding industrial visualization tasks, the GT1695M-XTBD operator terminal delivers high-resolution monitoring and control as part of the Mitsubishi Electric GOT1000 series. This high-performance human-machine interface (HMI) features a spacious 15-inch TFT color display, providing operators with clear, real-time diagnostic data and control capabilities directly on the factory floor.
| Parameter | Specification Value |
|---|---|
| Manufacturer | Mitsubishi Electric |
| Model Number | GT1695M-XTBD |
| Display Type | TFT Color LCD |
| Screen Size | 15 inches |
| Resolution | 1024 x 768 Pixels (XGA) |
| Display Colors | 65,536 Colors |
| Input Voltage | 24V DC (+25%, -20%) |
| Power Consumption | 19W or less (with backlight off) |
| Internal Memory | 15 MB Flash Memory |
| Front Protection Rating | IP67F (Dust-tight, water-resistant, oil-resistant) |
| Rear Protection Rating | IP20 |
| Operating Temperature | 0 to 50 degC |
| Country of Origin | Japan |
| Dimensions | 397 mm x 296 mm x 61 mm |
| Shipping Weight (Calculated) | 8.0 kg |
| Interface Port | Connector Type & Function |
|---|---|
| Ethernet | RJ-45 (10BASE-T/100BASE-TX) for PLC communication and network monitoring |
| RS-232 | D-Sub 9-pin (male) for PC connection, barcode readers, or legacy PLCs |
| RS-422/485 | D-Sub 9-pin (female) for multi-drop PLC networks and controller links |
| USB Host | USB-A (USB 2.0) for data storage, mouse, keyboard, or printer connection |
| USB Device | USB Mini-B (USB 2.0) for high-speed project upload/download from PC |
| Memory Card Slot | CF Card Interface for external backup, logging, and OS updates |
The GT1695M-XTBD can directly replace older GT15 series 15-inch models (such as the GT1595 series). Project files must be converted using GT Designer3 software. The panel cutout dimensions are identical, allowing for a drop-in physical replacement without modifying the enclosure door.
High ambient temperatures inside sealed control enclosures can significantly accelerate backlight degradation. Ensure adequate panel ventilation or cooling to maintain the HMI's ambient operating temperature below 50 degC. Avoid installing the unit in direct sunlight, as UV exposure can damage the resistive touch membrane over time.
When utilizing the RS-422/485 serial interface over long distances, ensure that the appropriate termination resistor is enabled via the HMI system settings. Always route communication cables (Ethernet and Serial) in separate conduits away from high-voltage motor drive cables to prevent electromagnetic interference (EMI) from disrupting touch screen inputs or communication links.
Prepare the panel cutout according to the official dimensions (383.5 mm x 282.5 mm). Ensure the mounting surface is flat and free of burrs to guarantee a proper IP67F seal.
Insert the HMI into the panel cutout from the front, ensuring the waterproof packing gasket is correctly positioned in its groove.
Secure the HMI using the provided mounting fixtures. Tighten the screws evenly to the specified torque (0.36 N-m to 0.48 N-m) to prevent panel deformation.
Connect the functional ground terminal (FG) on the rear of the unit to a dedicated class-D ground (100 ohms or less) using a minimum 2 mm square wire.
Global Express Shipping
Returns & Warranty
Manufacturer: Mitsubishi Electric
Product No.: GT1695M-XTBD
Country of origin:United States
Product Type: HMI Touch Screens
Payment: T/T, Western Union
Weight: 8000g
Dimensions: 397 mm x 296 mm x 61 mm
Shipping port: Xiamen
Warranty: 12 months
