GT2506HS-VTBD

Mitsubishi Electric

Mitsubishi Electric GT2506HS-VTBD GOT2000 Series Handy HMI

SKU GT2506HS-VTBD

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: GT2506HS-VTBD
  • Origin United States
  • Product Type: Handheld Human-Machine Interfaces
  • Payment: T/T, Western Union
  • Weight: 1.2 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

GOT2000 Series Handheld HMIs HMI
Quantità
Call sales Contact

Product Description

Description

Portable machine operation and monitoring are simplified with the GT2506HS-VTBD, a high-performance handheld Graphical Operation Terminal (GOT) from the Mitsubishi Electric GOT2000 Series. Designed for applications requiring mobility, this handy HMI allows operators to move freely around machinery or production lines while maintaining full control interface functionality.

Equipped with a 6.5-inch TFT color LCD, the unit delivers clear visualizations with its VGA resolution. The analog resistive touch panel provides highly responsive operator inputs, even when users are wearing industrial work gloves. Built-in physical control features, including preparation for safety equipment such as emergency stop switches, ensure the unit meets rigorous safety and operational standards in modern industrial environments.

Features

  • Clear 6.5-inch TFT color LCD screen with high-contrast VGA resolution.
  • Robust analog resistive touch panel supporting flexible on-screen operations.
  • Integrated dual-color power LED (blue and orange) for instant status feedback.
  • Lightweight, ergonomic handheld design minimizing operator fatigue during extended use.
  • Engineered for harsh environments with a wide operating temperature envelope.

Applications

  • Automated manufacturing cell setup and calibration
  • Robotic teaching pendant and system configuration
  • On-site machine maintenance and troubleshooting
  • Material handling and overhead crane control

Technical Specifications

Manufacturer Mitsubishi Electric
Part Number/Model GT2506HS-VTBD
Series GOT2000 Series (GT25 Handy)
Display Device TFT color LCD
Screen Size 6.5 inches
Resolution VGA (640 x 480 dots)
Display Dimensions 132.5 mm (W) x 99.4 mm (H)
Touch Panel Type Analog resistive film
Status Indicator Power LED (2 colors: blue and orange)
Operating Ambient Temperature 0 degC to 40 degC
Storage Ambient Temperature -20 degC to 60 degC
Operating/Storage Humidity 10% RH to 90% RH (non-condensing)
External Dimensions 201 mm (W) x 230 mm (H) x 97 mm (D) (excluding projections)
Weight 1.2 kg (GOT main unit only)

Installation Guidelines

To ensure safe and reliable handheld operation of the GT2506HS-VTBD, adhere to the following installation and handling instructions:

  • Ensure the dedicated connection cable is securely locked into the interface connector before powering on the device.
  • Protect the unit from direct exposure to constant liquids or oil mist to prevent degradation of the analog resistive screen.
  • Route the communication and power cable away from high-voltage motor cables to minimize electromagnetic interference.
  • Always utilize the integrated hand strap or mounting hooks when operating the terminal to prevent accidental drops.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the display size and resolution of the GT2506HS-VTBD?
The GT2506HS-VTBD features a 6.5-inch TFT color LCD screen with a VGA resolution of 640 x 480 dots.
Does the listed weight of 1.2 kg include the connection cable?
No, the weight of 1.2 kg is for the GT2506HS-VTBD main unit only. Cables and external connectors are not included in this measurement.
What are the storage and operating temperature parameters for this HMI?
The operating ambient temperature range is 0 degC to 40 degC, and the storage ambient temperature range is -20 degC to 60 degC.
What type of touch technology does the GT2506HS-VTBD use?
This model utilizes an analog resistive film touch panel, which allows operation with gloved hands or styluses.
