Description

Precision motion control and high-speed positioning operations utilize the Mitsubishi Electric HC-AQ0235D AC servo motor. As a core component of the HC-AQ series, this rotary motor is engineered for applications demanding rapid acceleration, minimal physical footprint, and precise speed regulation. Its ultra-low inertia rotor design ensures highly responsive performance when integrated with compatible Mitsubishi servo drive amplifiers.

The compact mechanical design of the HC-AQ0235D allows for seamless integration into dense machine architectures where space is at a premium. Built to industrial manufacturing standards, this motor delivers consistent torque output and reliable performance under continuous operating duty cycles.

Features

• Ultra-low rotor inertia optimized for high-frequency start/stop cycles.
• Compact structural dimensions with a variable dimension L of 61 mm.
• Robust thermal insulation for reliable winding performance under varied load conditions.
• High-accuracy feedback compatibility to ensure precise closed-loop positioning.

Applications

• Semiconductor fabrication and wafer handling machinery.
• High-speed pick-and-place packaging systems.
• Precision laboratory instrumentation and medical automation.
• Electronic component insertion and assembly systems.

Technical Specifications

Installation Guidelines

• Verify shaft alignment with the coupled load to prevent axial or radial overload on the bearings.
• Ensure the motor frame is securely grounded to the machine base to prevent electrical noise interference.
• Allow sufficient space around the motor housing for adequate convective heat dissipation.
• Do not subject the shaft end to direct impact or heavy shock during installation or coupling attachment.
