GT2508-STBA

Mitsubishi Electric

Mitsubishi Electric GT2508-STBA GOT2000 Series Graphic Operation Terminal

SKU GT2508-STBA

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: GT2508-STBA
  • Origin United States
  • Product Type: HMI Panels
  • Payment: T/T, Western Union
  • Weight: 0.5 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

GT25 Series HMI HMI HMI Panels
Quantità
Call sales Contact

Product Description

Description

Designed for robust industrial visualization, the GT2508-STBA functions as a high-performance human-machine interface within the Mitsubishi Electric GOT2000 Series. This module features an 8.4-inch TFT color display, providing SVGA resolution for crisp, clear graphic screens and diagnostic representations on the factory floor. Operating on an AC power supply (100 to 240 VAC), this HMI integrates seamlessly with MELSEC PLCs and various third-party automation components, serving as a centralized hub for monitoring, machine control, and system diagnostics.

Features

  • 8.4-inch TFT color display with SVGA resolution for clear, high-contrast industrial interfaces.
  • Integrated AC power supply accommodating wide-range input voltages from 100 to 240 VAC.
  • Multi-touch and gesture control functionality for intuitive operator navigation and safety controls.
  • Robust connectivity options including Ethernet, RS-232, RS-422/485, and USB interfaces for broad system integration.
  • Support for SD/SDHC memory cards to simplify data logging, system backups, and project transfers.
  • IP67F front panel protection rating against dust and water ingress when properly panel-mounted.

Applications

  • Automotive assembly lines and robotic work cell control.
  • Water and wastewater treatment monitoring panels.
  • Food and beverage packaging and processing machinery.
  • HVAC and environmental control systems in commercial and industrial facilities.

Technical Specifications

Manufacturer Mitsubishi Electric
Model / Part Number GT2508-STBA
Series GOT2000 (GT25)
Display Type TFT Color LCD
Screen Size 8.4 inches
Resolution SVGA
Frame Color Black
Power Supply Voltage 100 to 240 VAC (+10%, -15%)
Power Frequency 50 / 60 Hz (+/-5%)
Operating Temperature 0 to 55 degC (horizontal installation)
Storage Temperature -20 to 60 degC
Protection Rating IP67F (front panel when mounted)

Connections and Interfaces

Interface Port Function and Protocol Support
Ethernet Port RJ-45 (100BASE-TX / 10BASE-T) for network and PLC communications.
RS-232 Port D-sub 9-pin (male) for serial communication to controllers or peripherals.
RS-422/485 Port D-sub 9-pin (female) for multi-drop serial connection.
USB Host Type A port for USB memory storage, keyboards, or mouse connections.
USB Device Mini-B port for PC-to-HMI project transfer, programming, and debugging.
SD Card Slot Supports SD/SDHC cards for backup, restore, and local data logging.

Installation Guidelines

  • Ensure a minimum clearance of 100 mm at the top and bottom, and 50 mm on the sides from other equipment to allow proper air convection and cooling.
  • Mount the unit in a panel with a maximum thickness of 1.6 mm to 4.0 mm.
  • Tighten the panel mounting brackets to the specified torque range (0.36 to 0.48 N-m) to ensure the IP67F environmental sealing protection is maintained.
  • Connect the functional ground (FG) terminal directly to a dedicated class D ground (ground resistance 100 ohms or less) using a minimum 2 mm sq wire for electrical noise immunity.

Compliance and Certifications

  • CE (EMC Directive, Low Voltage Directive)
  • UL / cUL Listed
  • KC (Korea Certification)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the operating voltage range for the GT2508-STBA?
The GT2508-STBA operates on an AC power supply ranging from 100 to 240 VAC (50/60 Hz).
Does the GT2508-STBA support SD card memory storage?
Yes, the unit is equipped with an SD/SDHC card slot for data logging, backup, and project transfers.
What is the protection rating of this graphic operation terminal?
When mounted correctly in a control panel, the front panel of the GT2508-STBA carries an IP67F environmental protection rating.
