Engineered for high-precision motion control within the MELSERVO-JE series, the HG-SN152J-S100 provides robust performance in dynamic industrial positioning tasks. This AC servo motor delivers a nominal output of 1.5 kW, optimized for medium-inertia applications requiring reliable speed and torque regulation. Featuring an integrated oil seal, the mechanical structure is designed to withstand standard industrial operating environments while preventing fluid ingress at the shaft interface.
The unit features a totally enclosed, natural cooling design that achieves an IP67 protection rating (excluding the shaft-through portion). This makes it highly compatible with automated machinery across various sectors, ensuring long-term operational stability and seamless integration with companion MELSERVO-JE drive amplifiers.
| Manufacturer | Mitsubishi Electric |
| Model Designation | HG-SN152J-S100 |
| Series | MELSERVO-JE |
| Rated Output | 1.5 kW |
| Rated Torque | 7.16 Nm |
| Rated Speed | 2000 r/min |
| Maximum Speed | 3000 r/min |
| Instantaneous Permissible Speed | 3450 r/min |
| Rated Current | 9.4 A |
| Maximum Current | 29 A |
| Insulation Class | 155 (F) |
| Cooling Method | Totally enclosed, natural cooling |
| IP Rating | IP67 (excluding shaft-through portion) |
| Vibration Rank | V10 |
| Vibration Resistance | 24.5 m/s2 (X, Y directions) |
| Ambient Operating Temperature | 0 to 40 degC (non-freezing) |
| Ambient Storage Temperature | -15 to 70 degC (non-freezing) |
| Ambient Operating Humidity | 10% to 80% RH (non-condensing) |
| Ambient Storage Humidity | 10% to 90% RH (non-condensing) |
| Installation Altitude | Max 2000 m or less above sea level |
| Net Weight | 7.3 kg |
Global Express Shipping
Returns & Warranty
Manufacturer: Mitsubishi Electric
Product No.: HG-SN152J-S100
Country of origin:United States
Product Type: Servo Motors
Payment: T/T, Western Union
Weight: 7300g
Shipping port: Xiamen
Warranty: 12 months
