MR-J2-70A

Mitsubishi Electric

Mitsubishi Electric MR-J2-70A MR-J2 Servo Drive

SKU MR-J2-70A

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: MR-J2-70A
  • Origin United States
  • Product Type: Servo Drives
  • Payment: T/T, Western Union
  • Weight: 3.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

MR-J2 Series Servo Drives
Quantità
Call sales Contact

Product Description

Description

Designed for highly precise industrial motion control, the MR-J2-70A is a high-performance AC servo drive belonging to the Mitsubishi Electric MELSERVO-J2 series. This module uses an advanced sinusoidal PWM control and current control architecture to provide smooth torque delivery, exceptional positioning accuracy, and responsive speed control across varied load profiles. It is built to seamlessly interface with MELSERVO-compatible AC servo motors, offering robust performance in demanding production environments.

The unit features a dual-mode power input capability, operating on either a 3-phase or single-phase AC supply. Its integrated speed and position control loops allow for fine-tuning dynamics, making it an optimal selection for complex machinery synchronization and automated assembly setups.

Features

  • Sinusoidal PWM control and current control system for optimized motor operation.
  • Compatible with both 3-phase 200 to 230 V AC and single-phase 230 V AC input configurations.
  • High-speed response capability with a speed frequency response of 250 Hz or more.
  • Wide speed regulation range utilizing external analog voltage or internal digital parameter controls.
  • Robust thermal management designed for tight control cabinet integration.

Applications

  • Multi-axis CNC machine tool path control.
  • Automated packaging and labeling systems.
  • Precision material handling and product conveyor synchronization.
  • Textile machinery and high-speed printing presses.

Technical Specifications

Manufacturer Mitsubishi Electric
Model/Part Number MR-J2-70A
Series MELSERVO-J2
Product Type Servo Drive
Main Circuit Power Supply (3-Phase) 3-phase 200 to 230 V AC, 50/60 Hz
Main Circuit Power Supply (1-Phase) 1-phase 230 V AC, 50/60 Hz
Permissible Voltage Fluctuation (3-Phase) 170 to 253 V AC
Permissible Voltage Fluctuation (1-Phase) 207 to 253 V AC
Permissible Frequency Fluctuation +/- 5%
Control Method Sinusoidal PWM control / current control system
Speed Frequency Response 250 Hz or more
Speed Control Range (External Command) 1:1000 (0 to +/- 10 V DC / maximum speed)
Speed Control Range (Internal Command) 1:5000
Analog Speed Command Input 0 to +/- 10 V DC
Operating Ambient Temperature 0 to 55 degC
Shipping Weight 3.0 kg

Installation Guidelines

  • Mounting: Install the drive vertically on a flat, rigid panel surface inside a dust-free and oil-mist-free control cabinet.
  • Clearance: Maintain at least 10 mm of clear space on both left and right sides, and 40 mm above and below the unit to ensure adequate convective airflow.
  • Grounding: Connect the protective earth (PE) terminal securely to the system ground bus to prevent static buildup and mitigate electrical noise.
  • Wiring: Route high-voltage power lines and low-voltage command cables through separate conduits to prevent electromagnetic interference.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What power supply options does the MR-J2-70A servo drive support?
The MR-J2-70A supports 3-phase 200 to 230 V AC at 50/60 Hz, as well as 1-phase 230 V AC at 50/60 Hz.
What is the speed control range of the MR-J2-70A?
The drive offers a speed control range of 1:1000 when using an external analog command, and 1:5000 when utilizing internal commands.
What environmental conditions are required for operating the MR-J2-70A?
The servo drive is designed to operate reliably in ambient temperatures ranging from 0 to 55 degC.
Reviews

More from this brand

Mitsubishi Electric Q06UDEHCPU MELSEC-Q Series Universal PLC CPU Module
Q06UDHCPUMitsubishi Electric Q06UDEHCPU MELSEC-Q Series Universal PLC CPU Module
Mitsubishi Electric FX3U-128MR/ES-A | FX3U Series Main Unit
FX3U-128MR/ES-AMitsubishi Electric FX3U-128MR/ES-A | FX3U Series Main Unit
Mitsubishi MELSEC MR-J3-40A Servo Amplifier | 400W 3-Phase or 1-Phase 200V
MR-J3-40AMitsubishi MELSEC MR-J3-40A Servo Amplifier | 400W 3-Phase or 1-Phase 200V
Mitsubishi MR-J2S-40A-S004 | 400W AC Servo Amplifier
MR-J2S-40A-S004Mitsubishi MR-J2S-40A-S004 | 400W AC Servo Amplifier

MR-J2-70A

Stock & lead time on request

Call
  • MR-J2-70A
1 1

Mitsubishi Electric MR-J2-70A MR-J2 Servo Drive

Only 10 item(s) left in stock

  • Manufacturer: Mitsubishi Electric

  • Product No.: MR-J2-70A

  • Country of origin:United States

  • Product Type: Servo Drives

  • Payment: T/T, Western Union

  • Weight: 3000g

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

Designed for highly precise industrial motion control, the MR-J2-70A is a high-performance AC servo drive belonging to the Mitsubishi Electric MELSERVO-J2 series. This module uses an advanced sinusoidal PWM control and current control architecture to provide smooth torque delivery, exceptional positioning accuracy, and responsive speed control across varied load profiles. It is built to seamlessly interface with MELSERVO-compatible AC servo motors, offering robust performance in demanding production environments.

The unit features a dual-mode power input capability, operating on either a 3-phase or single-phase AC supply. Its integrated speed and position control loops allow for fine-tuning dynamics, making it an optimal selection for complex machinery synchronization and automated assembly setups.

Features

  • Sinusoidal PWM control and current control system for optimized motor operation.
  • Compatible with both 3-phase 200 to 230 V AC and single-phase 230 V AC input configurations.
  • High-speed response capability with a speed frequency response of 250 Hz or more.
  • Wide speed regulation range utilizing external analog voltage or internal digital parameter controls.
  • Robust thermal management designed for tight control cabinet integration.

Applications

  • Multi-axis CNC machine tool path control.
  • Automated packaging and labeling systems.
  • Precision material handling and product conveyor synchronization.
  • Textile machinery and high-speed printing presses.

Technical Specifications

Manufacturer Mitsubishi Electric
Model/Part Number MR-J2-70A
Series MELSERVO-J2
Product Type Servo Drive
Main Circuit Power Supply (3-Phase) 3-phase 200 to 230 V AC, 50/60 Hz
Main Circuit Power Supply (1-Phase) 1-phase 230 V AC, 50/60 Hz
Permissible Voltage Fluctuation (3-Phase) 170 to 253 V AC
Permissible Voltage Fluctuation (1-Phase) 207 to 253 V AC
Permissible Frequency Fluctuation +/- 5%
Control Method Sinusoidal PWM control / current control system
Speed Frequency Response 250 Hz or more
Speed Control Range (External Command) 1:1000 (0 to +/- 10 V DC / maximum speed)
Speed Control Range (Internal Command) 1:5000
Analog Speed Command Input 0 to +/- 10 V DC
Operating Ambient Temperature 0 to 55 degC
Shipping Weight 3.0 kg

Installation Guidelines

  • Mounting: Install the drive vertically on a flat, rigid panel surface inside a dust-free and oil-mist-free control cabinet.
  • Clearance: Maintain at least 10 mm of clear space on both left and right sides, and 40 mm above and below the unit to ensure adequate convective airflow.
  • Grounding: Connect the protective earth (PE) terminal securely to the system ground bus to prevent static buildup and mitigate electrical noise.
  • Wiring: Route high-voltage power lines and low-voltage command cables through separate conduits to prevent electromagnetic interference.
Key Features:
#MR-J2 Series #Servo Drives

What power supply options does the MR-J2-70A servo drive support?
The MR-J2-70A supports 3-phase 200 to 230 V AC at 50/60 Hz, as well as 1-phase 230 V AC at 50/60 Hz.

What is the speed control range of the MR-J2-70A?
The drive offers a speed control range of 1:1000 when using an external analog command, and 1:5000 when utilizing internal commands.

What environmental conditions are required for operating the MR-J2-70A?
The servo drive is designed to operate reliably in ambient temperatures ranging from 0 to 55 degC.

Global Express Shipping

  • Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).


For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
