Description

Engineered for high-performance motion control, the Mitsubishi Electric MR-J3-350A serves as a robust servo amplifier within the MELSERVO-J3 product family. This unit utilizes advanced sinusoidal PWM control to deliver precise speed, torque, and position management for compatible industrial rotary servo motors. Designed for general-purpose applications, the "A" variant interfaces seamlessly via analog voltage or pulse-train command inputs, ensuring compatibility with a wide range of open-loop and closed-loop motion controllers.

The system features a high-speed CPU to minimize processing delay, combined with an adaptive vibration suppression algorithm that mitigates mechanical resonance during high-speed positioning tasks. The integration of high-resolution encoder processing ensures exceptional tracking and control performance under dynamic load variations.

Features

• General-purpose command interface accepting analog voltage and pulse-train inputs.
• Real-time auto-tuning function that automatically adjusts control gains based on mechanical load inertia.
• Advanced vibration suppression control to limit mechanical oscillations at both the load end and the machine base.
• Support for high-resolution absolute and incremental encoders.
• Built-in regenerative resistor for absorbing deceleration energy, with support for external braking options.
• Sinusoidal PWM control system with high-precision current loop response.

Applications

• Packaging machinery and automated wrapping systems.
• Material handling and high-speed pick-and-place gantry systems.
• Textile manufacturing and winding machinery.
• CNC machine tool feed axes.
• Semiconductor fabrication and wafer handling systems.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mounting Orientation: Install the amplifier vertically on a flat, rigid panel to ensure proper heat dissipation.
• Clearances: Maintain at least 10 mm of clearance on the left and right, and 40 mm at the top and bottom of the unit for natural convection cooling.
• Grounding: Connect the Protective Earth (PE) terminal securely to the cabinet ground bus to minimize electromagnetic noise and prevent electric shock.
• Wiring: Route high-power motor cables (U, V, W) separately from low-voltage signal cables (CN1, CN2) to prevent signal interference. Use shielded cables for encoder and control lines.

Compliance and Certifications

• CE Mark (Low Voltage and EMC Directives)
• UL Listed (UL 508C)
• cUL
