Mitsubishi Electric Q06UDEHCPU (215808) MELSEC-Q Series Universal Q CPU Module

SKU Q06UDEHCPU

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Mitsubishi Electric
Product No.: Q06UDEHCPU
Origin United States
Product Type: PLC CPU Modules
Payment: T/T, Western Union
Weight: 0.22 kg
Dimensions: 98 mm x 27.4 mm x 89.3 mm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Designed for high-speed sequence control and seamless network integration, the Q06UDEHCPU functions as a high-performance Universal Q CPU module within the Mitsubishi Electric MELSEC-Q automation platform. This module features built-in Ethernet and USB communication ports, allowing direct integration into factory networks and programming environments without requiring separate communication modules.

The Q06UDEHCPU offers a program capacity of 60k steps and processes basic instructions at an ultra-fast speed of 9.5 ns. This execution speed, paired with its multi-CPU capability, makes it highly suitable for complex, multi-axis motion control, assembly lines, and high-speed packaging machinery. The module supports up to 4096 local I/O points and can scale up to 8192 points using remote I/O networks.

Features

Built-in 100BASE-TX/10BASE-T Ethernet port for host system connectivity, peer-to-peer data exchange, and engineering software access.
Integrated USB (Mini-B) port for direct connection to programming and monitoring software.
High-speed logic processing with a basic instruction execution time of 9.5 ns.
Large memory configuration supporting 60k steps of program capacity.
Comprehensive self-diagnostic features including watchdog timer, battery failure detection, program checks, and power supply monitoring.
Multi-CPU configuration compatibility on the same base unit to distribute control tasks.

Applications

Automotive assembly and welding systems
Semiconductor manufacturing machinery
High-speed packaging and filling operations
Water and wastewater processing plants
Material handling and automated warehousing

Technical Specifications

Manufacturer	Mitsubishi Electric
Part Number / Model	Q06UDEHCPU (215808)
Series	MELSEC-Q Series
Product Type	Universal Q CPU Module
Program Capacity	60k steps (240k bytes)
Basic Instruction Execution Speed	9.5 ns
Memory Type	RAM, ROM, Flash
Local I/O Points	4096 points
Total I/O Points (with Remote I/O)	8192 points
Communication Ports	1x Ethernet (RJ45), 1x USB (Mini-B)
Current Consumption (5 VDC)	0.39 A
Operating Temperature	0 to 55 degC
Storage Temperature	-25 to 75 degC
Dimensions (H x W x D)	98 mm x 27.4 mm x 89.3 mm
Weight	0.22 kg

Connections and Interfaces

Interface Port	Connection Type	Function
Ethernet	RJ45 (100BASE-TX/10BASE-T)	System programming, host communication, and MC Protocol data exchange
USB	Mini-B	Direct engineering software connection (GX Works2 / GX Developer)

Installation Guidelines

Always switch off the external power supply before mounting or removing the CPU module from the base unit.
Securely lock the module onto the MELSEC-Q main base unit using the upper and lower fixing hooks.
Ensure proper system grounding by connecting the ground terminal of the power supply module to a dedicated class-D ground (100 ohms or less).
Route Ethernet and communication cabling away from high-voltage AC lines to prevent electromagnetic noise interference.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the difference between the Q06UDEHCPU and standard Q06UDCPU modules?

The Q06UDEHCPU features a built-in Ethernet port (indicated by the 'E' in the model name) in addition to the standard USB port, allowing for direct network integration without requiring an external Ethernet module.

What programming software is compatible with the Q06UDEHCPU?

This module is configured and programmed using Mitsubishi Electric's GX Works2 or GX Developer engineering software.

How many local I/O points can this module control directly?

The Q06UDEHCPU can manage up to 4096 local I/O points directly on the base unit and extension units.

Does this module require a backup battery?

Yes, a lithium battery (such as the Q6BAT) is required to maintain program data and clock settings in the event of a primary power loss.
