Managing complex multi-axis synchronization, the Mitsubishi Electric Q173CPUN-T provides robust motion control capabilities within the MELSEC Q Series PLC platform. This specialized module mounts directly to the system backplane to handle multi-axis coordination and path planning calculations independently of the primary sequence PLC CPU. Supporting up to 32 axes of motion control, it is optimized for high-performance machine automation. The module integrates support for hand-held teaching units, allowing commissioning technicians and engineers to carry out on-site positioning tests, adjustments, and diagnostics without relying entirely on external computer interfaces.
| Specification Parameter | Value / Rating |
|---|---|
| Manufacturer | Mitsubishi Electric |
| Model Number | Q173CPUN-T |
| Series | MELSEC Q Series |
| Device Type | Motion Controller CPU Module |
| Number of Controlled Axes | 32 Axes |
| Current Consumption (5 VDC) | 1.56 A |
| Teaching Unit Compatibility | Usable |
| Dimensions (H x W x D) | 11.43 cm x 2.74 cm x 9.80 cm |
| Net Weight | 0.24 kg |
| Shipping Weight (Calculated) | 3.00 kg |
The Q173CPUN-T module requires a compatible MELSEC Q multi-CPU backplane configuration. It is designed to operate in tandem with a main PLC CPU module (such as the Q02H, Q06H, or newer Universal models). Always verify the firmware revision compatibility of both CPUs to prevent synchronization faults during initial power-up cycles.
Because this module draws a substantial current load of 1.56 A at 5 VDC from the system backplane, engineers must perform a complete power budget calculation for the rack power supply module (e.g., Q61P, Q63P). An over-current condition on the 5 VDC rail will trigger a power supply fault, stopping both the PLC logic processing and all active multi-axis motion control loops simultaneously.
When integrating a teaching unit with the module, ensure the connecting interface is seated fully and locked. Route high-speed external motion network and feedback cables inside isolated metallic conduits separated from heavy motor power lines to reduce the coupling of electro-magnetic interference into the controller's logic circuits.
Isolate all primary line voltage and auxiliary power sources feeding the controller chassis and servo-drive systems before mounting or demounting this module. Failure to de-energize equipment prior to physical manipulation risks catastrophic system backplane damage, internal circuit destruction, and severe electrical shock hazards.
Global Express Shipping
Returns & Warranty
Manufacturer: Mitsubishi Electric
Product No.: Q173CPUN-T
Country of origin:United States
Product Type: Motion Controllers
Payment: T/T, Western Union
Weight: 3000g
Dimensions: 11.43 cm x 2.74 cm x 9.80 cm
Shipping port: Xiamen
Warranty: 12 months
