Mitsubishi Electric Q10UDEHCPU MELSEC-Q Series Universal CPU Module

SKU Q10UDEHCPU

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Mitsubishi Electric
Product No.: Q10UDEHCPU
Origin United States
Product Type: CPU Modules
Payment: T/T, Western Union
Weight: 0.22 kg
Dimensions: 98 mm x 27.4 mm x 115 mm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Designed for demanding automation environments, the Q10UDEHCPU serves as a high-performance Universal Q-Series programmable controller CPU. This module features a high-speed processor capable of executing basic instructions (LD X0) in 9.5 nanoseconds and structured transfer instructions (MOV D0 D1) in 19 nanoseconds. With an integrated 100/10 Mbps Ethernet port, it simplifies network deployment, programming, and data exchange with SCADA, HMI, or higher-level enterprise systems. It provides robust memory management with a 100K-step program capacity, support for multiple programming languages (including ladder, SFC, and structured text), and massive device memory allocation suitable for mid-to-high-scale control architectures.

Features

High-Speed Execution: Processes basic LD instructions in 9.5 ns and MOV instructions in 19 ns.
Substantial Memory Capacity: Features a 100K-step (400 KB) program capacity alongside multiple storage options including RAM and ROM flash drives.
Built-in Ethernet: Features an integrated 10/100 Mbps RJ45 port supporting up to 16 simultaneous socket, MELSOFT, and MC protocol connections.
Multi-Language Programming: Supports Relay symbol, MELSAP 3 (SFC), MELSAP-L, Function Block (FB), and Structured Text (ST).
Multi-CPU Capability: Includes a 32 KB high-speed communication area for high-performance multi-CPU operations.

Applications

Automotive manufacturing and assembly lines
Water and wastewater treatment facilities
Material handling and high-speed logistics sorting systems
Complex HVAC and environmental control networks
Food and beverage processing systems

Technical Specifications

Parameter	Specification Value
Manufacturer	Mitsubishi Electric
Part Number / Model	Q10UDEHCPU
Series	MELSEC-Q Series (Universal QCPU)
Control Method	Stored program iteration operation
I/O Control Method	Refresh method (Direct access I/O possible via DX/DY specification)
Basic Instruction Execution Speed (LD X0)	9.5 ns
Data Transfer Execution Speed (MOV D0 D1)	19 ns
Program Capacity	100K steps (400 KB)
Built-in Ethernet Interface	100Base-TX / 10Base-T (RJ45 port)
Max. Number of I/O Device Points	8192 points (X/Y 0 to 1FFF)
Max. Number of Physical I/O Points	4096 points (X/Y 0 to FFF)
Internal Current Consumption (5V DC)	0.49 A
Operating Ambient Temperature	0 to 55 degC
Storage Ambient Temperature	-25 to 75 degC
Ambient Operating Humidity	5 to 95% RH (non-condensing)
Vibration Resistance	Meets JIS B 3502 and IEC 61131-2 standards
Impact Resistance	147 m/s square, 3 times in X, Y, and Z axes
Dimensions (H x W x D)	98 mm x 27.4 mm x 115 mm
Weight	0.22 kg

Connections and Interfaces

Interface / Port	Function and Protocol Support
Built-in Ethernet Port	RJ45 port; supports 100Base-TX/10Base-T, MELSOFT connection, MC protocol, Socket communication, and FTP (1 connection).
Memory Card Slot	Supports external SRAM, Flash, or ATA memory cards for program and file register storage.
Base Unit Connector	Connects directly to MELSEC-Q Series main base plates and multi-CPU high-speed bus.

Installation Guidelines

Mount the CPU module securely on a compatible MELSEC-Q Series base unit (main base plate).
Ensure all power is disconnected from the base unit prior to mounting or removing the CPU module.
To minimize electromagnetic interference, route all communication and Ethernet cabling separate from high-voltage AC or motor drive cabling.
Install the system within a dry, dust-free control cabinet with adequate ventilation clearance to maintain ambient temperatures below 55 degC.
Ground the base plate using standard industrial grounding practices to prevent electrical noise and static buildup.

Compliance and Certifications

IEC 61131-2 Compliant (Programmable Controllers)
JIS B 3502 Compliant

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the basic instruction execution speed of the Q10UDEHCPU?

The CPU executes basic instructions (such as LD X0) in 9.5 nanoseconds and structured transfer instructions (such as MOV D0 D1) in 19 nanoseconds.

Does the Q10UDEHCPU have built-in Ethernet communication?

Yes, it features an integrated 100Base-TX/10Base-T Ethernet port supporting up to 16 simultaneous socket, MELSOFT, or MC protocol connections, plus 1 connection dedicated to FTP.

What is the maximum program capacity supported by this module?

The module has a program capacity of 100K steps, which corresponds to 400 KB of program memory.

What are the physical dimensions and weight of the CPU?

The module measures 98 mm (H) x 27.4 mm (W) x 115 mm (D) and weighs approximately 0.22 kg.

Which programming languages are compatible with this CPU?

It supports Relay symbol word, logic symbolic word, MELSAP 3 (SFC), MELSAP-L, Function Blocks, and Structured Text (ST).
