Q25PRHCPU

Mitsubishi Electric

Mitsubishi Electric Q25PRHCPU MELSEC-Q Series Redundant CPU Module

SKU Q25PRHCPU

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: Q25PRHCPU
  • Origin United States
  • Product Type: Redundant CPU Modules
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

MELSEC Q Series Redundant CPU Modules
Quantità
Call sales Contact

Product Description

Description

Engineered for high-availability industrial control architectures, the Q25PRHCPU is a high-performance redundant CPU module belonging to the Mitsubishi Electric MELSEC-Q Series platform. This controller is designed to mitigate system downtime by supporting hot-standby redundant configurations, making it suitable for continuous process applications. Operating under a stored program cyclic execution method with refresh-mode I/O control, it delivers reliable execution of complex sequence and process control logic.

The Q25PRHCPU features a generous 252K-step program capacity and integrates a versatile memory card interface compatible with SRAM, Flash, and ATA cards. Processing efficiency is highlighted by an ultra-fast instruction execution speed of 34 ns for basic LD instructions and 102 ns for MOV instructions. With its broad instruction set and robust physical construction, this redundant processor ensures seamless system integration and maximum process continuity.

Features

  • Redundant system architecture to prevent operational shutdowns in critical applications.
  • Rapid execution speeds with 34 ns LD instruction and 0.78 us floating-point addition times.
  • Large-scale logic processing capacity supporting up to 252K program steps.
  • Flexible memory expansion via dedicated SRAM, Flash, and ATA memory card interfaces.
  • Supports both sequence control and process control programming languages for versatile application deployment.
  • Constant scan settings configurable from 0.5 ms to 2000 ms in 0.5 ms increments.

Applications

  • Power generation and distribution control systems.
  • Water and wastewater treatment facilities.
  • Continuous chemical and petrochemical processing plants.
  • Large-scale infrastructure and HVAC control networks.

Technical Specifications

Manufacturer Mitsubishi Electric
Model / Part Number Q25PRHCPU
Series MELSEC-Q Series [QnU]
Module Type Redundant CPU Module
Control Method Stored program cyclic operation
I/O Control Mode Refresh
Program Language Sequence control language, Process control language
Program Capacity 252K steps
LD Instruction Execution Speed 34 ns
MOV Instruction Execution Speed 102 ns
Floating Point Addition Speed 0.78 us
PC MIX Value 10.3 instructions/us
Total Number of Instructions 778
Constant Scan Setting Range 0.5 to 2000 ms (adjustable in units of 0.5 ms)
Memory Card Interface Slots SRAM card, Flash card, ATA card
Shipping Weight 2 kg

Installation Guidelines

  • Mount the module strictly onto a compatible MELSEC-Q redundant main base unit.
  • Ensure system power is fully isolated before installing or removing the CPU module from the backplane.
  • Provide adequate ventilation space around the rack assembly as specified in the MELSEC-Q series hardware manual.
  • Maintain robust grounding of the base unit to minimize electromagnetic interference (EMI) in high-noise industrial environments.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the Mitsubishi Electric Q25PRHCPU?
The Q25PRHCPU is a redundant CPU module designed for the MELSEC-Q series, providing hot-standby redundancy to ensure continuous process operation and minimize system downtime.
What is the program capacity of the Q25PRHCPU module?
The module features a high program capacity of up to 252K steps.
Which memory card types are supported by this CPU?
The onboard memory card interface supports SRAM cards, Flash cards, and ATA cards.
What are the instruction processing speeds of this unit?
The Q25PRHCPU executes basic LD instructions in 34 ns and MOV instructions in 102 ns.
