Designed for high-precision motion control, the QD75MH4 positioning module provides multi-axis synchronization and rapid response capability within the MELSEC-Q platform. This motion control module supports up to 4 axes of control, operating on a high-speed serial communication interface designed for seamless integration with Mitsubishi general-purpose AC servo amplifiers, specifically the MR-J3-B series. By utilizing a dedicated high-speed bus structure, it achieves an operation cycle of 1.77ms, significantly reducing latency and improving synchronization compared to legacy positioning systems.
The QD75MH4 is engineered for complex motion profiles, handling up to 600 positioning data points per axis. It includes robust external input interfaces for limits, stops, and manual pulse generators, making it a reliable solution for automated manufacturing, packaging machinery, and material handling systems requiring strict positioning accuracy.
| Mitsubishi Electric |
| QD75MH4 |
| MELSEC-Q Series |
| Up to 4 axes |
| 600 data points per axis |
| 1.77 ms |
| High-speed serial communication system (SSCNET III compatible) |
| Mitsubishi General-Purpose AC Servo (MR-J3-B) |
| 24VDC level, 1 point per module |
| A-phase / B-phase, 5VDC level, 1 point per module |
| 2 kg |
| Interface / Signal Type | Specification / Layout |
|---|---|
| Upper stroke limit, lower stroke limit, proximity dog, stop, speed/position switching signal (24VDC level, 5 points/axis) | |
| 24VDC level, 1 point/module (safety shut-off input) | |
| A-phase/B-phase, 5VDC level, 1 point/module | |
| SSCNET high-speed fiber optic connection port |
