The NX-ECC202 is an EtherCAT Coupler Unit from the NX-series, designed to act as the primary interface between an EtherCAT network master and the distributed NX-series I/O modules. This unit facilitates high-speed, deterministic data exchange, supporting up to 63 connectable NX Units on a single slave node. Utilizing the 100BASE-TX (IEEE 802.3) physical layer with a 100 Mbps baud rate, the NX-ECC202 ensures seamless synchronization and communication within complex machine control architectures. The device is intended for panel mounting and requires integration into an EtherCAT network managed by a compatible master controller.
| Parameter | Specification |
|---|---|
| Manufacturer | Omron |
| Model | NX-ECC202 |
| Product Type | EtherCAT Coupler Unit |
| Max Connectable Units | 63 |
| Communications Protocol | EtherCAT |
| Baud Rate | 100 Mbps |
| Physical Layer | 100BASE-TX (IEEE 802.3) |
| Enclosure | Panel Mounted |
| Grounding | 100 Ohm or less |
| Dimensions | 7.1 cm x 4.6 cm x 10 cm |
| Shipping Weight | 2 kg |
Global Express Shipping
Returns & Warranty
Manufacturer: Omron
Product No.: NX-ECC202
Country of origin:Japan
Product Type: NX-series EtherCAT® Coupler Unit
Payment: T/T, Western Union
Weight: 2000g
Dimensions: 7.1 cm x 4.6 cm x 10 cm
Shipping port: Xiamen
Warranty: 12 months
The NX-ECC202 is an EtherCAT Coupler Unit from the NX-series, designed to act as the primary interface between an EtherCAT network master and the distributed NX-series I/O modules. This unit facilitates high-speed, deterministic data exchange, supporting up to 63 connectable NX Units on a single slave node. Utilizing the 100BASE-TX (IEEE 802.3) physical layer with a 100 Mbps baud rate, the NX-ECC202 ensures seamless synchronization and communication within complex machine control architectures. The device is intended for panel mounting and requires integration into an EtherCAT network managed by a compatible master controller.
| Parameter | Specification |
|---|---|
| Manufacturer | Omron |
| Model | NX-ECC202 |
| Product Type | EtherCAT Coupler Unit |
| Max Connectable Units | 63 |
| Communications Protocol | EtherCAT |
| Baud Rate | 100 Mbps |
| Physical Layer | 100BASE-TX (IEEE 802.3) |
| Enclosure | Panel Mounted |
| Grounding | 100 Ohm or less |
| Dimensions | 7.1 cm x 4.6 cm x 10 cm |
| Shipping Weight | 2 kg |
