Description

The ATV630C13N4F is a high-capacity frequency controller from the Altivar Process ATV630 range, engineered for demanding industrial motor control applications. With a rated power of 132 kW and an operating voltage range of 380-480V, this variable frequency drive is designed to enhance process efficiency and energy management. The unit features an IP21-rated enclosure, providing protection against solid objects and vertical water drops. The ATV630C13N4F serves as an essential component in large-scale industrial fluid management, material handling, and processing operations, offering robust motor torque control and advanced system diagnostic capabilities.

Features

• Optimized for high-power 132 kW motor control.
• Supports 380-480V three-phase power supply.
• Integrated into the Altivar Process ATV630 platform for advanced monitoring.
• IP21 ingress protection for indoor industrial cabinet installations.
• Designed for long-term reliability in process-heavy environments.

Applications

• Large-scale industrial water and wastewater treatment pumps.
• High-capacity fan and ventilation systems.
• Mining and mineral processing equipment.
• Heavy-duty material handling and conveying lines.

Technical Specifications

Installation Guidelines

• Handling: Given the 366.00 kg weight, use appropriate heavy-lifting equipment for transport and installation.
• Mounting: Ensure the floor or support structure is rated to handle the significant static load of the drive.
• Cooling: The ATV630C13N4F generates substantial heat; ensure the installation area has sufficient ventilation and airflow clearance according to the manual.
• Grounding: Verify that all grounding points are secure to comply with electrical safety standards and reduce common-mode noise.
• Environment: Install in a clean, dry, and climate-controlled environment to maintain the longevity of the electronics.
