Schneider Electric CAD50F7 TeSys D Auxiliary Contactor

SKU CAD50F7

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: CAD50F7
  • Origin France
  • Product Type: Auxiliary Contactors
  • Payment: T/T, Western Union
  • Weight: 0.36 kg
  • Dimensions: 11,2cm x 9,2cm x 5cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Auxiliary Contactors
Quantità
Call sales Contact

Product Description



Description

The CAD50F7 is a robust TeSys D auxiliary contactor manufactured by Schneider Electric, designed for reliable switching and control of auxiliary circuits. Engineered to operate at voltages up to 690 V AC, this contactor features a 110 V AC control voltage. It is equipped with five normally open (NO) contacts, providing high-density signal handling in a compact form factor. Featuring secure screw clamp terminal connections, the CAD50F7 is built for durability and consistent performance in demanding industrial control panels and automation systems.

Features

  • Contactor Type: Auxiliary contactor (5 NO contacts)
  • Control Voltage: 110 V AC
  • Operating Voltage: Up to 690 V AC
  • Connection: Secure screw clamp terminals
  • Design: Compact housing for efficient cabinet utilization
  • Durability: High mechanical and electrical reliability for industrial environments

Applications

  • Industrial control and automation systems
  • Motor control centers and starter assemblies
  • Signal switching for complex electrical circuits
  • Interlocking and auxiliary control logic
  • General-purpose industrial panel wiring

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Brand Tesys D
Product Type Auxiliary contactors
Control Voltage 110 V AC
Max. Operating Voltage 690 V AC
Dimensions 11.20 cm x 9.20 cm x 5.00 cm
Weight 0.36 kg
Commodity Code 85364900
ECCN N
Product Phase Active

Installation Guidelines

  • Mounting: Can be mounted on a 35 mm DIN rail or fixed directly to a panel surface using screws.
  • Wiring: Use appropriate wire gauges for the screw terminals to ensure secure electrical contact. Tighten screws to the recommended torque specifications provided in the manufacturer's manual.
  • Environment: Install in a clean, dry location protected from excessive dust, vibrations, and extreme temperatures.
  • Testing: Verify the control voltage supply (110 V AC) before initial energization to prevent coil damage.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the control voltage for the CAD50F7?
The control voltage for this auxiliary contactor is 110 V AC.
How many contacts does this model have?
The CAD50F7 is equipped with 5 normally open (NO) auxiliary contacts.
What type of terminals does this contactor use?
It utilizes screw clamp terminals for secure and reliable electrical connections.
What is the product status of the TeSys D auxiliary contactors?
The TeSys D series is currently in the active lifecycle phase.
