Schneider Electric TSXDEZ08A4 Modicon TSX Micro AC Discrete Input Module

SKU TSXDEZ08A4

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: TSXDEZ08A4
Origin France
Product Type: Discrete Input Modules
Payment: T/T, Western Union
Weight: 1.08 kg
Dimensions: 18.00 cm x 25.50 cm x 5.50 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Designed for seamless integration with Modicon TSX Micro programmable logic controllers, the TSXDEZ08A4 provides reliable signal detection for industrial automation environments. This high-density AC discrete input module features 8 independent channels designed to monitor alternating current status signals from field devices such as limit switches, pushbuttons, and sensors. Its robust construction ensures stable operation and precise signal conditioning within demanding electrical control panels, making it an essential component for maintaining or upgrading legacy Modicon TSX Micro control architectures.

Features

Provides 8 discrete AC input channels for comprehensive field device monitoring.
Engineered specifically for compatibility with the Schneider Electric Modicon TSX Micro PLC platform.
Compact modular form factor optimizes space utilization within electrical enclosures.
Reliable signal isolation protects sensitive control electronics from electrical noise and transients.
Easy slot-in installation minimizes system downtime during maintenance or expansion.

Applications

Manufacturing assembly lines and machinery control.
Motor control centers (MCC) and pump control panels.
Material handling and conveyor systems.
Legacy system retrofits and industrial automation upgrades.

Technical Specifications

ManufacturerPart Number/ModelSeriesModule TypeInput ChannelsInput TypeWeightDimensionsCommodity Code

Schneider Electric

TSXDEZ08A4

Modicon TSX Micro

Discrete Input Module

AC (Alternating Current)

1.08 kg

18.00 cm x 25.50 cm x 5.50 cm

85389091

Installation Guidelines

To ensure safe and reliable operation of the TSXDEZ08A4 module, adhere to the following engineering practices:

Power Down: Always disconnect all power sources to the PLC rack and field wiring before inserting, removing, or wiring the module.
Mounting: Align the module with the designated slot guides on the Modicon TSX Micro backplane and slide it in until it is fully seated and locked.
Wiring Separation: Route high-voltage AC input wiring separately from low-voltage DC signal lines and communication cables to prevent electromagnetic interference.
Grounding: Ensure the PLC rack chassis is properly grounded in accordance with local electrical codes and standards.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the Schneider Electric TSXDEZ08A4?

The TSXDEZ08A4 is an 8-channel AC discrete input module designed to interface external AC control signals from field devices with a Modicon TSX Micro PLC system.

Which PLC platform is compatible with the TSXDEZ08A4 module?

This module is specifically designed for use with the Schneider Electric Modicon TSX Micro controller series.

What are the physical dimensions and weight of the TSXDEZ08A4?

The module has dimensions of approximately 18.00 cm x 25.50 cm x 5.50 cm and weighs 1.08 kg.

Is it safe to hot-swap the TSXDEZ08A4 module?

No, you must always power down the PLC rack and disconnect field wiring before installing or removing the TSXDEZ08A4 module to prevent damage to the equipment.
