Schneider Magelis XBT XBTZGCO2 Mechanical Adapter

SKU XBTZGCO2

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: XBTZGCO2
Origin France
Product Type: Accessories
Payment: T/T, Western Union
Weight: 0.39 kg
Dimensions: 21,5cm x 16cm x 8cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The XBTZGCO2 is a Mechanical Adapter designed for the Magelis XBT series, engineered by Schneider Electric. This mounting accessory is specifically configured to facilitate the physical replacement and exchange of an XBTF032-10 terminal with an XBTGT2-0 series HMI. It ensures proper alignment and panel fitment, allowing for efficient system upgrades without the need for extensive panel modification.

Features

Designed for precise physical compatibility between XBTF and XBTGT terminal series
Enables seamless mechanical exchange of XBTF032-10 with XBTGT2-0 models
Robust construction for secure HMI mounting
Simplifies retrofitting and system modernization processes

Applications

HMI system upgrades and modernization
Retrofitting legacy Magelis XBTF terminals
Control panel maintenance and equipment exchange

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Range	Magelis XBT GT
Model	XBTZGCO2
Product Type	Mechanical adapter
Compatibility	XBTF032-10 to XBTGT2-0
Weight	0.39kg
Dimensions	21.5cm x 16cm x 8cm
Commodity Code	73269098
PLM Product Status	Phase-Out

Installation Guidelines

Preparation: Ensure the existing panel cutout is clean and free of debris from the previous terminal removal.
Alignment: Position the XBTZGCO2 adapter accurately over the panel opening. Follow the provided template or manual for correct orientation relative to the new terminal.
Mounting: Secure the adapter to the panel using the provided hardware. Ensure the fit is flush to maintain the enclosure's integrity.
HMI Integration: Mount the XBTGT2-0 terminal into the adapter frame according to the HMI's specific mounting instructions, ensuring the gasket forms a proper seal against the adapter surface.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the XBTZGCO2?

The XBTZGCO2 is a mechanical adapter that allows an XBTGT2-0 terminal to fit into the panel cutout previously occupied by an XBTF032-10 model.

Does this adapter include electrical components?

No, the XBTZGCO2 is a mechanical mounting accessory only and does not contain active electrical circuitry.

Is this product still in production?

No, the XBTZGCO2 is currently in the phase-out stage of its product lifecycle.
