Description

The TSXCBY1000 is a Bus-X extension cable featuring loose ends, two line testers, and a length of 100 meters for Modicon Premium automation architectures. Manufactured by Schneider Electric, this accessory cable is engineered to interconnect racks and remote drop stations within distributed industrial control networks, ensuring reliable data communication across the system.

Built to withstand demanding industrial environments, the TSXCBY1000 provides robust signal transmission capabilities necessary for maintaining network integrity in complex PLC installations. The unit features physical dimensions of 45 x 45 x 27 cm and an operational weight of 18.00 kg. As an active lifecycle product, it supports ongoing system expansion, maintenance, and reliable connectivity for established industrial control networks.

Features

• 100-meter continuous Bus-X cable length for distributed rack configurations
• Loose-end design with two integrated line testers for system integration
• Robust physical construction optimized for industrial network routing
• Modicon Premium automation system compatibility
• Active product lifecycle status ensuring ongoing availability

Applications

• Distributed PLC rack interconnection in industrial environments
• Remote drop station communication wiring
• Factory automation network expansion and maintenance
• Legacy Modicon Premium system infrastructure deployment

Technical Specifications

Installation Guidelines

• Route the TSXCBY1000 cable carefully through industrial cable trays or conduits, avoiding sharp bends or excessive tensile stress.
• Maintain proper separation between communication cables and high-voltage power lines to prevent electromagnetic interference (EMI).
• Terminate the loose end securely to the appropriate rack communication modules in accordance with system wiring specifications.
• Utilize the integrated line testers to verify signal continuity and network termination integrity prior to powering on the control system.
