Description

The Schneider Electric BMXDAI1603 is a Modicon X80 discrete input module designed for M340 automation systems. This module features 16 discrete inputs operating at a voltage of 48 V AC with an input current of 5 mA, providing reliable signal acquisition for industrial control architectures. Built with compact dimensions of 12 x 11 x 5.5 cm and a lightweight construction of 0.15 kg, it integrates directly into standard Modicon X80 drop racks. It maintains an active lifecycle status, making it a reliable solution for factory automation and process control applications.

Features

• Equipped with 16 discrete input channels for industrial signal monitoring
• Operates at 48 V AC with a 5 mA input current specification
• Designed for seamless integration within the Modicon X80 and M340 automation platforms
• Compact physical form factor measuring 12 x 11 x 5.5 cm
• Lightweight construction weighing 0.15 kg to minimize backplane stress

Applications

• Modicon M340 PLC and distributed I/O rack architectures
• Factory automation and discrete manufacturing control systems
• Industrial machinery and equipment signal acquisition
• Process monitoring and status verification panels

Technical Specifications

Connections/Interfaces

Installation Guidelines

• Ensure backplane power is completely disconnected before inserting or removing the BMXDAI1603 module.
• Align the module carefully with the designated slot on the Modicon X80 rack and secure it using the integrated locking mechanism.
• Connect field signal wiring to the removable terminal block in accordance with the system wiring diagrams.
• Ensure proper cable routing away from high-voltage power lines to minimize electromagnetic interference (EMI).
• Verify channel status indicators via the front panel LEDs upon system power-up.
