Designed for demanding industrial environments, the Weidmuller IE-SW-VL05M-3TX-2SC (Article Number 1504330000) is a high-performance managed Fast Ethernet switch engineered to facilitate reliable data transmission in automated networks. This device integrates three copper RJ45 ports and two multi-mode fiber optic SC-Duplex ports, supporting transmission distances up to 5 km. Its managed functionality allows for optimized traffic control, network monitoring, and enhanced security protocols across distributed industrial architectures.
Housed in a rugged IP30-rated metal enclosure, this switch is built to withstand mechanical stress and extreme thermal variations. It features a store-and-forward data switching mechanism to ensure error-free packet delivery. Dual redundant power inputs (12/24/48 V DC) provide continuous operation and system resilience in the event of a primary power supply failure, making it highly suitable for critical infrastructure applications.
| Manufacturer | Weidmuller |
| Part Number / Model | IE-SW-VL05M-3TX-2SC (1504330000) |
| Switch Type | Managed Fast Ethernet |
| Transmission Rate | 100 Mbps |
| Transceiver Type | Multimode |
| Connector Type | SC-Duplex (Fiber), RJ45 (Copper) |
| Transmission Distance (Typical) | 5 km |
| Data Switching | Store and Forward |
| MAC Table Size | 2 K |
| Packet Buffer Size | 1 Mbit |
| Voltage Supply | 12/24/48 V DC (2 redundant inputs) |
| Connection Type | 1 removable 6-pin terminal block |
| Housing Material | Metal |
| Protection Degree | IP30 |
| Mounting Type | DIN rail, Panel (with optional mounting kit) |
| Operating Temperature | 0 degC to 60 degC |
| Storage Temperature | -40 degC to 85 degC |
| Operating Humidity | 5% to 95% (non-condensing) |
| Width | 53.6 mm |
| Height | 135 mm |
| Depth | 105 mm |
| Net Weight | 650 g |
| Interface / Pin | Function / Connection Type |
|---|---|
| Ports 1 to 3 | RJ45 10/100BaseT(X) copper auto-negotiation |
| Ports 4 to 5 | 100BaseFX multi-mode fiber optic (SC-Duplex) |
| 6-Pin Terminal Block | Power input 1 (V1+/V1-), Power input 2 (V2+/V2-), Fault contact, Ground |
