The Woodward 5466-332 is a High-Density Analog I/O Module designed for use within the MicroNet control system architecture. The module features 24 analog inputs (4-20 mA) with reduced filtering on channels 23 and 24, as well as 8 analog outputs (4-20 mA) configured for simplex applications. It provides precise signal acquisition and stable control outputs using high-resolution digital-to-analog converters to ensure exact signal reproduction across critical industrial applications. Equipped with standard communication interfaces, the Woodward 5466-332 integrates into existing control systems to communicate directly with PLCs, DCSs, and main system controllers across industrial environments.
| Parameter | Specification |
|---|---|
| Manufacturer | Woodward |
| Part Number | 5466-332 |
| Product Type | High-Density Analog I/O Module |
| Country of Manufacture | United States (USA) |
| Input Channels | 24 Analog Inputs (4-20 mA) |
| Output Channels | 8 Analog Outputs (4-20 mA) |
| Filtering | Reduced filtering on input channels 23/24 |
| Application Type | Simplex |
| Temperature Drift | 125 ppm/C, maximum |
| Readback Accuracy | 0.5% of 0-25 mA full scale |
| Readback Temperature Drift | 400 ppm/C, maximum |
| Connector Pin | Function |
|---|---|
| Top Sub D Connector | Analog Input Channels 1 to 12, Analog Output Channels 1 to 4 |
| Bottom Sub D Connector | Analog Input Channels 13 to 24, Analog Output Channels 5 to 8 |
