Siemens 7MH4950-1AA01 SIWAREX U Modul Penimbang

Description

The Siemens 7MH4950-1AA01 is a high-precision SIWAREX U weighing module designed for the SIMATIC S7-300 and ET200M automation systems. This single-channel module is engineered to measure weights with high accuracy in industrial applications, such as platform scales, hopper scales, or force-measuring devices. It offers versatile communication capabilities, including an RS232 interface for PC parameterization and a TTY interface for connecting remote displays, making it an essential tool for precise process integration and weight monitoring.

Features

• Single-Channel Design: Optimized for connecting one scale.
• Seamless Integration: Designed for direct rack mounting with SIMATIC S7-300 and ET200M systems.
• Flexible Communication: Features RS232 for PC setup and TTY for remote display/annunciators.
• High Precision: Provides accurate weight data for complex process automation.
• Reliability: Built to withstand demanding industrial process environments.

Applications

• Industrial platform scales and tank weighing
• Hopper and silo weight monitoring
• Force measurement in production machinery
• Material handling and inventory automation

Technical Specifications

Installation Guidelines

• Mounting: Slide the module onto the S7-300 mounting rail and connect it to the backplane bus using the provided bus connector.
• Wiring: Use shielded cable for the load cell connection to minimize noise interference. Ensure the shield is properly grounded at the module or via the designated earthing terminal.
• Configuration: Use the RS232 interface to connect a PC with SIWAREX U software to calibrate the scale and set operational parameters.
• Remote Display: Use the TTY interface specifically for connecting remote weight displays to ensure distance communication without electromagnetic interference.
