BECKHOFF CP7901-0000-0000 CP79xx Economy Control Panel

Only 10 item(s) left in stock

Manufacturer: BECKHOFF
Product No.: CP7901-0000-0000
Country of origin:Niemcy
Product Type: Control Panels
Payment: T/T, Western Union
Weight: 8000g
Shipping port: Xiamen
Warranty: 12 months

Description

Industrial visualization and operator control are streamlined with the CP7901-0000-0000, a high-performance Economy Control Panel designed by Beckhoff. This unit features a 12-inch TFT display with a resolution of 800 x 600 pixels, integrated into a robust aluminum housing engineered to withstand demanding industrial environments. By utilizing specialized DVI-E and USB-E 2.0 connection technology, this industrial control panel can operate at distances of up to 50 meters from the control PC, offering exceptional flexibility in physical system layout and installation.

Features

12-inch high-contrast display with an 800 x 600 pixel resolution.
Durable aluminum housing with an IP65 protection rating for reliable operation in harsh environments.
DVI-E and USB-E 2.0 connection technology enabling remote operation up to 50 meters from the host PC.
USB-E 2.0 interface supporting high-speed data transmission up to 480 Mbit/s.
Integrated mounting arm adapter with 4 threaded M6 x 18 mm holes on the backplane.
Compatible with standard DVI outputs of industrial PCs.

Applications

Machine-level human-machine interface (HMI) and visualization.
Automotive manufacturing and assembly lines.
Process automation requiring remote display positioning.
Food and beverage production environments requiring IP65 protection.

Technical Specifications

ManufacturerPart Number/ModelSeriesDisplay SizeResolutionHousing MaterialProtection RatingConnection TechnologyTransmission DistanceUSB Transmission RatePower SupplyOperating TemperatureMountingWeight

BECKHOFF

CP7901-0000-0000

CP79xx

12-inch

800 x 600 pixels

Aluminum

IP65

DVI-E and USB-E 2.0

Up to 50 m

480 Mbit/s

24 V DC

0 to 55 degC

4 x M6 x 18 mm threaded holes in backplane

8 kg (Shipping Weight)

Connections and Interfaces

Interface Connection	Function
DVI-E Input	Receives video signals from standard PC DVI output over extended distances
USB-E 2.0	Transmits USB 2.0 data at 480 Mbit/s with IP65-rated connectors

Installation Guidelines

Mounting: Secure the control panel using the 4 threaded M6 x 18 mm holes located on the backplane mounting arm adapter. Ensure the mounting structure can support the unit's weight.
Cabling: Use only certified DVI-E and USB-E 2.0 cabling to guarantee signal integrity and performance up to the maximum 50-meter limit.
Environmental: Maintain adequate clearance around the housing to ensure passive cooling keeps the operating temperature within the specified 0 to 55 degC range.
Grounding: Ensure the aluminum housing is properly grounded to the machine frame to prevent electrical noise and interference.

Key Features:

#Beckhoff CP79xx #Control Panels

What is the maximum distance the CP7901-0000-0000 can be installed from the PC?

The CP7901-0000-0000 utilizes DVI-E and USB-E 2.0 connection technology, allowing it to be operated at a distance of up to 50 meters from the control PC.

What is the protection rating of the Beckhoff CP7901-0000-0000?

The control panel features an IP65 protection rating, which applies to both the aluminum housing and the connection interfaces.

How is this control panel mounted?

It is designed for mounting arm installation using 4 threaded holes (M6 x 18 mm) located on the backplane adapter.
