Schneider Electric TSXETC100 Modicon Premium Ethernet/IP Network Module

Description

The TSXETC100 is an Ethernet/IP network module engineered for the Modicon Premium automation platform by Schneider Electric. This communication module supports data transmission speeds of 10/100 Mbit/s, providing robust connectivity for industrial network infrastructures. It is designed for seamless integration into Modicon Premium racks to facilitate high-speed data exchange and system monitoring in demanding automation environments.

Features

• Ethernet/IP protocol support
• Data transmission rates: 10/100 Mbit/s
• Designed for Modicon Premium automation architectures
• Robust industrial communication performance
• IP20-rated protection

Applications

• Industrial automation network infrastructure
• Real-time data exchange in distributed control systems
• Remote monitoring and system management
• Industrial network expansion and integration

Technical Specifications

Installation Guidelines

• Mounting: Secure the module within the Modicon Premium backplane/rack to ensure reliable electrical connection.
• Wiring: Use appropriate Cat5e or Cat6 Ethernet cabling to maintain the 100 Mbit/s data transmission integrity.
• Network Segregation: Ensure industrial networks are properly segregated from general office traffic to minimize broadcast storms and interference.
• Grounding: Verify the rack chassis is correctly grounded to comply with electromagnetic compatibility standards.
• Environment: Install in a controlled environment protected from excessive moisture, dust, and corrosive gases.
