ABB HESG447260R2 70BA01C-S PROCONTROL P13 Bus End Module

Q: What is the power supply requirement for this module?

The module operates on a 24 V DC power supply with a current consumption of 40 mA or less.

Q: What isolation rating does the device provide?

The unit provides 500 V DC isolation between the bus and logic circuits.

Q: What is the operating temperature range for the bus end module?

The device is rated for operation in ambient temperatures ranging from -20 degC to +70 degC.

SKU HESG447260R2 70BA01C-S

In stock

12-month warranty
Free returns within 30 days

Manufacturer: ABB
Product No.: HESG447260R2 70BA01C-S
Country of origin:Sweden
Product Type: Bus End Module
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 150g
Dimensions: 147 mm x 200 mm x 16 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Description

The ABB HESG447260R2 70BA01C-S is a specialized bus termination unit designed for integration within the PROCONTROL P13 automation and control platform. The HESG447260R2 70BA01C-S serves as a vital signal conditioning and bus-end component, ensuring proper bus impedance matching and signal reflection suppression across the internal backplane bus. Utilizing a 24 V DC auxiliary supply with low power consumption, it maintains reliable noise immunity and system signal integrity for critical industrial and power generation applications.

Features

Specialized termination design for the PROCONTROL P13 system bus.
Low current consumption of 40 mA or less at 24 V DC supply.
High surge withstand capability of 2 kV (1.2/50 us).
Integrated electrical isolation of 500 V DC between bus and logic circuits.
Extended operating temperature range suitable for harsh industrial environments.

Applications

PROCONTROL P13 control and monitoring system racks.
Signal conditioning and termination in power plant automation architectures.
Backplane communication protection for industrial process control racks.

Technical Specifications

Parameter	Value
Manufacturer	ABB
Product Model	HESG447260R2 70BA01C-S
Spare Model	70BA01c-S
Module Type	Bus End Module
System Compatibility	PROCONTROL P13 System
Power Supply	24 V DC
Module Current	<= 40 mA
Surge Withstand	2 kV 1.2/50 us
Isolation	500 V DC bus-to-logic
Operating Temperature	-20 degC ... +70 degC
Operating Humidity	0 - 95 % RH non-condensing
Country of Origin	Sweden
Tariff Code	8537101190
Dimensions	1.6 x 20 x 14.7 cm
Weight	0.15 kg

Installation Guidelines

Ensure system auxiliary supply power is turned off before inserting or removing the unit from the rack chassis.
Install the unit securely in the designated bus end slot of the PROCONTROL P13 rack to maintain correct bus impedance.
Maintain proper rack grounding and shielding practices to preserve the specified 2 kV surge withstand rating.
Ensure ambient temperature within the cabinet remains within -20 degC to +70 degC during operation.

FAQ

What is the power supply requirement for this module?

The module operates on a 24 V DC power supply with a current consumption of 40 mA or less.

What isolation rating does the device provide?

The unit provides 500 V DC isolation between the bus and logic circuits.

What is the operating temperature range for the bus end module?

The device is rated for operation in ambient temperatures ranging from -20 degC to +70 degC.
