Manufacturer: ABB
Product No.: HIEE401238R1 XVB363 AE
Country of origin:Switzerland
Product Type: Printed Circuit Boards
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 700g
Dimensions: 40 mm x 198 mm x 262 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
The ABB XVB363 AE HIEE401238R1 is a high-performance CIRCUIT BOARD designed for industrial power electronics and gate drive control application tracks. Operating as a critical firing and interface layer, this board provides a nominal input voltage of 24V DC (±10%) with a typical power consumption of 8W to regulate high-power semiconductor assemblies. The hardware provides robust electrical isolation with an isolation voltage of 4kV AC, delivering stable gate drive output signaling of ±15V optimized for exact IGBT control. Engineered to interface seamlessly with 1700V and 3300V modules at switching frequencies up to 2kHz, the board integrates critical protection parameters, including a desat protection response time of less than 2μs and a short-circuit protection trip time of 10μs or less to safeguard the system loop from transient electrical faults.
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Model | XVB363 AE HIEE401238R1 |
| Module Type | CIRCUIT BOARD |
| Input Voltage | 24V DC (±10%) |
| Power Consumption | 8W (typical) |
| Isolation Voltage | 4kV AC |
| Gate Drive Output | ±15V (IGBT control) |
| Switching Frequency | Up to 2kHz |
| Supported IGBTs | 1700V/3300V modules |
| Desat Protection | <2μs response time |
| Short-Circuit Protection | ≤10μs trip time |
| Operating Temp | -25 degC to +70 degC |
| Storage Temp | -40 degC to +85 degC |
| Humidity | 5-95% RH (non-condensing) |
| Country of Origin | SWEDEN |
| Tariff Code | 8537101190 |
| Weight | 0.7 kg |
