Manufacturer: Allen-Bradley
Product No.: 2711P-T12W22D9P
Country of origin:United States
Product Type: Graphic Terminals
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 2580g
Dimensions: 246 mm x 340 mm x 69.6 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
The 2711P-T12W22D9P is an operator interface device engineered to monitor and control industrial equipment connected to ControlLogix and CompactLogix 5370 controllers over an EtherNet/IP network. This performance model features animated graphic displays and text screens that provide critical visibility into machine and process operational states. Operating on a Windows 10 IoT Core platform, the terminal leverages FactoryTalk View Machine Edition software to create a highly flexible and interactive automation control interface. Equipped with dual Ethernet ports supporting complex network topologies, the 2711P-T12W22D9P is designed for deployment across a wide range of demanding industrial manufacturing environments.
| Attribute | Specification Value |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Model | 2711P-T12W22D9P |
| Operator Input | Touch |
| Display Type | TFT Color |
| Display Size | 12.1-in. wide screen |
| Viewing Area (W x H) | 261 x 163 mm (10.3 x 6.4 in.) |
| Display Resolution | 1280 x 800 WXGA, 24-bit color graphics (Series B) |
| Aspect Ratio | 16:10 |
| Brightness | 300 cd/m2 (Nits) or more |
| Backlight Life | White light-emitting diode, solid-state; 50,000 h min at 40 degC |
| Touch Screen Type | Analog resistive (Actuation: 1 million presses; Operating force: 100 g) |
| Battery Type | CR2032 lithium coin cell (Life: 4 years min at 25 degC) |
| Real-Time Clock Accuracy | ±2 minutes per month |
| System Memory (Series B) | 4 GB RAM and 19.87 GB storage |
| User Memory (Series B) | 2 GB, approx, nonvolatile storage for applications |
| SD Card Slot | One slot supporting 1784-SDx and 1784-SDHCx cards |
| USB Host Ports (Series B) | One USB high-speed 3.0 host port, one USB 2.0 host port (Type A) |
| USB Device Ports | One high-speed 2.0 device port (Type B) |
| Operating System (Series B) | Windows 10 IoT Core |
| Ethernet Ports | Two 10/100Base-T, Auto MDI/MDIX Ethernet ports |
| Configuration Software | FactoryTalk View Studio for Machine Edition, FactoryTalk ViewPoint v2.6 or later |
| Input Voltage | 24V DC nominal (18...30V DC) |
| Power Consumption (Series B) | 32 W max |
| Power Supply Support | Safety Extra Low Voltage (SELV) and Protective Extra Low Voltage (PELV) |
| Temperature, Operating | 0...55 degC (32...131 °F) |
| Temperature, Nonoperating | -25...+70 degC (-13...+158 °F) |
| Relative Humidity | 5...95% without condensation |
| Operating Altitude | 2000 m (6562 ft) |
| Enclosure Ratings | NEMA and UL Type 12, 13, 4X, IP66 |
